PCB Lay out Main Board Printed Circuit Board PCBA Manufacturing PCB

 PCBA Assembly Green Board PCBA Provide SMT Lead-Free PCB AssemblyFabrication of PCB, acquire components and assemble PCB:Fastline Circuits is capable of providing full turnkey and partial turnkey printed circuit boardassembly services. For full turnkey, we take care of the entire process, including preparation of Printed Circuit Boards, procurement of components, online order tracking, continuousmonitoring of quality and final assembly. Whereas for partial turn-key, the customer can provide the PCBs and certain components, and the remaining parts will be handled by us.Features-Our Products Advantage1. Over 10 years of experience manufacturer in PCBA Pcb Assembly and PCB field.2.  Big scale of producing makes sure that your purchase cost is lower.3. Advanced production line guarantees stable quality and long life span.4. Design and produce almost any PCB as your requirement.5. 100% test for all customized PCB products6. One-stop Service, we can help to purchase the componentsPls see our PCB catalog below:1. single-sided PCB2. double sided PCB3. Multilayer PCB(3-26+ layers)4. Flexible PCB(FPC)5. Rigid-flex PCB board6. Aluminum PCB board for LED(1-4 layers)7. MCPCB board (1-4 layers)8.Ceramic PCB(1-4 layers)9. HDI PCB board10. High-frequency PCB 11. PCB assembly PCB  Manufacture  CapabilityItem   Manufacture  CapabilityLayers   1-26  LayersHDI 2+N+2Material  Types Fr-4,   Fr-5,   High-Tg,   Aluminum  Based  , Halogen  Free,                                                                                              Isola,   Taconic,   Arlon,   Teflon,   Rogers,  Max.   Panel  Dimension39000mil  *  47000mil  (1000mm  *  1200mm)Outline  Tolerance ± 4mil  (± 0.10mm)Board  Thickness8mil-236mil  (0.2  -  6.0mm)   Board  Thickness  Tolerance ± 10%Dielectric  Thickness 3mil-8mil  (  0.075mm-0.20mm)Min.   Track  Width 3mil  (  0.075mm  )Min.   Track  Space3mil  (  0.075mm  )External  Cu  Thickness 0.5  OZ  -  10  OZ  (  17um  -  350um)Internal  Cu  Thickness   0.5OZ  -  6OZ  (  17um  -  210um)Drilling  Bit  Size  (  CNC  ) 6mil-256mil  (  0.15mm  -  6.50mm)Finished  Hole  Dimension       4mil-236mil(0.1mm  -  6.0mm)Hole  Tolerance± 2mil  (± 0.05mm)Laser  Drilling  Hole  Size   4mil(0.1mm)Aspect  Ration 16: 1Solder  MaskGreen,   Blue,   White,   Black,   Red,   Yellow,   Purple,   etc.Min  Solder  mask  Bridge2mil(0.050mm)Plugged  Hole  Diameter8mil-20mil  (  0.20mm-0.50mm)Beveling30o  -  45oV-scoring+/-0.1mm,   15o    30o    45o    60o Impedance  Control                               Min. 5%    General  ± 10%Surface  Finishing HASL,   HASL(lead  Free),   Immersion  Gold Immersion  Silver,   OSP,   Hard  Gold  (  up  to  100u" )CertificationUL  RoHS  ISO9001: 2000  ISO14000: 2004  SGSTestingFlying  probe, E-TEST,   X-RAY  Inspection  , AOIFilesGerber  Protel  DXP  Auto  CAD  PADS  OrCAD  Express  PCB  etc  PCB advantages:1 R&D team support 2 UL, RoHS,ISO9001,SGS3.IPC class24.Advanced production line and prompt delivery.5, Honest Credibility in China.6. Professional and abundant experience in PCB.7.Competitive price and good quality.8. Excellent after-sales service.Trade Terms:1. We have no MOQ.2. Payment Term: T/T or Western Union.3. Delivery ways: UPS, FedEx, DHL, etc, door to door service by sea or air, etc. Application:1. Consumer electronics.2. Industrial control.3. medical instrument.4. fire service implement etc. Our Service:1. Reply your enquiry in 2 working hours.2.Experienced staffs answer all your questions in fluent English.3.Customized design is avaliable OEM&ODM are welcomed.4. Exclusive and unique solution can be provided to our customer by our well-trained and professional engineers and staffs.5. Special discount and protection of sales area provided to our distributor. PCB  Prototype  Lead  Time:itemGeneral  timeQuick  Turn1-24  days1 day4-6  Layers6  days2  days8-10  Layers8  days3  days12-16  Layers12  days4days18-20  Layers14  days5  days22-26  Layers16  days6  daysNote: Base on all data received by us and must be complete and problem-free, Lead time is ready to ship time.PCBA Technology:1)Professional Surface-mounting and Through-hole soldering Technology.2)Various sizes like 1206,0805,0603,0201, 1005 components SMT technology.3) ICT(In-Circuit Test), FCT(Functional Circuit Test) technology.4) PCB Assembly With UL, CE, FCC, RoHS Approval.5) Nitrogen gas reflow soldering technology for SMT.6) High Standard SMT&Solder Assembly Line.7) High density interconnected board placement technology capacity.Types of Assembly: THD (Thru-Hole Device); SMT (Surface-Mount Technology) ; SMT & THD mixed; 2 sided SMT and THD assemblySMT Line Quantity: 30SMT Min Pitch-QFP: 0.3mmBGA-Min Pitch: 0.25mmComponent Package: Reels; Cut tape; Tube and tray; Loose parts and bulkBoard dimensions: Smallest size: 50*50mm ; Largest size: 520*420mmBoard shape: Rectangular; Round; Slots and Cutouts; Complex and IrregularBoard type: Rigid FR-4 ; Rigid-Flex boards ; Aluminum PCBAssembly process: Lead-Free (RoHS)Design file format: Gerb
