Tecon Aluminum Frame Formwork Alu-Deck Formwork

TECON Aluminum frame formwork alu-deck formwork  Brief IntroductionTECON Aluminum frame formwork alu-deck formwork(TECON  Aludeck Formwork )is one of the most efficient and labour-saving panel slab formworks. With highly light aluminium frame panels, safe handy and high loading capacity aluminium props, easy to learn assembly sequence and slab forming can be implemented rapidly in residential and industrial construction projects with thicker slabs.Techinical Specification- TMP Props with Built-in taps and safe stopping device makes safe and fast operation. - For slab thickness up to 100cm with 150cm main beam, and up to 40cm with 225cm main beam. - Flexible solution with specially designed accessories for infill area around columns or edge of slab near walls. - 750/500/375mm width by 1500/750mm length aluminium panels lined with TECON-Form birch, the biggest size panel 750*1500mm only weights 16.2kg.  ModelTMP120TMP250TMP350TMP480TMP625Min.Length (mm)8001450198026004300Max.Length (mm)12002500350048006250Weight (Kg)10.415.518.723.830.2Min~ Max Load (kN)70~9060~7042~8825~8520-56As shown below, aluminium TMP Props range from 800mm to 625mm and have a maximum workload of up to 90kN. Features-Lightweight aluminium panels and props make it a handset slab formwork. - Powder-coated frame, beams and props outer tube thus effortless and fast cleaning. - Table transforming is available by connecting props, beams and panels together with truss bracing. - Early stripping heads reduce on-site material requirements and result in quick deployment of panels. - High load capacity TMP Aluminum prop means lower density slab props required, around 0.3 pieces per m² only. Similar formwork Our Service* ConsultancyOffer you a general idea of formwork & scaffold among TECON various systems, to fit your project demand.* Technical PlanningCustomized forming & shoring solution proposal according to your structural drawing by Auto-cad.* Order DeliveryFrom fabrication to loading, fast to your site with standard export packages.* On-site SupervisionShop drawing, user manual, and even send our supervisor to your site for training and supervision.Test report will be available according to different norms from different regions in order to offer no worries to clients or meet destination authority requirements.TECON Certification of Quality will be issued when the certain batch of products passes finished products inspection together with all QC profiles in previous phases.Pre-shipment inspection will be also supported according to clients' request or by third-party.Company InformationAs the specialist in formwork & scaffolding engineering area, TECON devotes itself in providing better products & services for our customers in construction industry all over the world.Thanks to TECON experienced technical team, safety, cost-effective and efficiency have already been considered even at the very beginning of product development. At TECON, you will experience excellent one-stop service throughojut the whole phases of your projects, from budgeting to completion. We assist you with optimal technical planning, order delivering, on-site supervising, and even more than these. We have a wide range of products line which covers wall formwork, slab formwork, column formwork, climbing formwork, slip formwork, girder, plywood, shoring prop, and all kinds of scaffoldings.They are widely used in residential & commercial buildings, fly-over roads, bridges, tanks, dams and other civil engineering projects. TECON business is built on working with customers together and striving to satisfy all their requirements, with its know-how, reliable quality & in-time service. TECON, for those who build./* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
