Hot Sale Paper Loader Aligning Stacker Machine Fully Automated Paper Loading Machine

 QZ1450F /QZ1650FMachine Performance1.The paper unloader can be used in conjunction with program-controlled paper cutters, lifters, paper breakers and air cushion workstations to form a cutting line, which can automatically complete the cutting, feeding and unloading, sorting, handling and stacking of paper, with many features such as high production efficiency, low operating labour intensity, short auxiliary production time and reduced labour costs.2.It greatly facilitates the feeding and unloading of paper stacks during the cutting process. The high quality stacking function provides the necessary prerequisites for future printing or folding processes, saving time and effort. The fully automatic paper size adjustment function guarantees simple operation.    Configuration ListingNo.NameBrand, specification & model1SensorFOTEK2Air SwitchTE3AC ContactorTE4ButtonTE or Eton5Platform servo motorsPlatform Walking(Inovance)6Servo DriverWalking Control(Inovance)7Servo motorPick-up part(Inovance)8Photoelectric SensorDetecting the height of paper stacks(LEUZE)9Switch Power TE10Power SwitchCANSEN11Miniature RelayTE12Combination valvesHydraulic Part(WAISN)13Air cylinderCatch paper part(AirTAC)15Linear GuiderHigh accurate linear guides16Display screensMCGS Technical Parameter XZ1450F-2XZ1650F-2Plate Size(W×L)mm1050×18001300×2040Max.Paper size(W×L)mm1010×14501270×1650Min.Paper size(W×L)mm300×400300×400Max.Layer height(with plate)mm16001600Max.Layer height mm165165Min. table height from the floor mm150 150 Max.Layer weight Kg400450Pressure setting MPa0.35-0.40.35-0.4Air Demand MPa0.6 0.6 Air supply consumption L /min33Rated voltage V380/220380/220Power supply modeThree-phase five-wire systemThree-phase five-wire systemGross Power Kw5.85.8Min.grams of paper g5050Unloader time S25-3525-35Net Weight KG23002400Gross Weight KG24502550Machine Size(WXLXH)mm3920×2100×20604330×2350×2060Packing Size(WXLXH)mm4100×2380×22104300×2380×2210Hydraulic drive for lifting and lowering, smooth movement, low noise, long life and low maintenance costsThe recommended power of the air compressor alone is 2.2Kw CertificateCompany/* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
