Cable Fault Locating System Underground Pipe Cable Fault Locator

Product Description :China Cable Fault Locator Cable Fault Locating System Test Equipment TesterFind details about China Lab EquipmentTesting Equipment from Cable Fault Locator Cable Fault Locating System Test Equipment Tester1.Introduction is a high performance underground metallic pipe locating system.It consists a transmitter and a receiver, can be used to do route tracing, pipe exploration and depth measurement of the underground cables and metallic pipes.It can also be used to identify target cable from a bunch of cables,locate the pipe insulation damage and part type cable fault.  Click more details :   2.Product Pictures                                       3.Function features:Compass display: to display pipe position directly.Left/right arrow indication: use the left/right arrow to indicate the pipe position when route tracing.Right/wrong indication: real-time test the pipe current direction to indicate tracing result and avoid the nearby lines interference.Real-time depth measure and current measure.History curve display: to display the signal variation directly.Cable Identification: Clamp (optional) identification and sensor identification. Clamp identification can precisely gives accurate result. sensor (optional) identification could be used when the Clamp identification is not applicable.Grounding fault location: Use the A frame (optional) to pinpoint the pipe insulation damaged points against the ground. No need to do zero set and the arrow will point to the fault point direction.Digitization high accuracy sampling and processing,narrow receiving pass band to rise the anti-interference capability and suppress power interference and harmonic interference from nearby running cable and pipe.Multiple locating frequency: active detection and passive detection.Multiple signal output mode: Direct connection output, Clamp Coupling input, Radiation output.Big capacity Li-on batteries series,support auto power off when low battery or long time no operationSolid case and light weight easy to carry4.SPECIFICATION Transmitter:Output: Direct Connection output, Clamp Coupling Output (optional), Radiation output. Output Frequency:640Hz (complex frequency), 1280Hz (complex frequency), 10kHz, 33kHz, 83kHz.197khzOutput power: max. 10W, 10 levels adjustable, auto impedance matching.Direct connection voltage: max. 150Vpp.Overload and short circuit protection.HMI: 128X64 LCD.Power supply: 4 X built-in 18650 Li-on batteries, standard 7.4V, 6.8Ah.  Receiver:Input: Internal receiving loop, Clamp (optional), sensor (optional),fault locating A Frame (optional).Receiving frequency:       - Active frequency: 640Hz,1280Hz,10kHz,33kHz,83kHz 197KHZ      - Power frequency: 50Hz/60Hz,250Hz/300Hz      - Radiation frequency passive frequency: center frequency 10kHz, 33kHz, 83kHz  Pipe detection mode: wide peak method,narrow peak method,valley methodCable identification mode: Receiving Clamp (optional) intelligent identification and sensor (optional) identificationHMI: 320X240 LCDBuilt-in battery: 2 X 18650 Li-on batteries, standard 7.4V,3.4AhOther:Volume: transmitter 270x220x85mm,receiver 700x270x120mmWeight: transmitter 2.2kgs, receiver 2.2kgs Charger: input AC 100~240V,50/60Hz,output DC8.4V,2ATemperature: -10-40ºC,humidity 5-90%,elevation
