Hot Sale Electromagnetic Flow Meter

Double separation weighing multiphase measuring device  can realize the continuous measurement of gas and liquid production, temperature and pressure through the alternating work of two separators, and is equipped with water cut measuring equipment to measure comprehensive water cut. The whole measuring process is automatically controlled by computer. The measuring device can be equipped with RTU and other equipment to realize remote data transmission and remote monitoring.1. MPFM diagramStainless steel electromagnetic flowmeters are designed for accurate and stable measurement of instantaneous flow, cumulative flow, and flow of conducting liquids and grout in closed pipesSpeed, such as: clean water, sewage, domestic water, raw water, all kinds of acid, alkali, salt and other solutions, mud, pulp, pulp and food sideSurface liquid, etc., widely used in metallurgy, paper, water treatment, chemical, light industry, textile, food and beverage, catering, agricultural irrigationThe irrigation, hydropower station, oilfield, electric power and mining industries2.Technical parameters   Function: Automatic metering for tested well   Design presser :3500psi   Design temperature : 100ºC   Inlet : 2 7/8" thread (f)   Outlet : 2 7/8" thread (f)Metering for liquid: 200-3500 bpd,  Accuracy : 3%Metering for water cut: 0-100%,  Accuracy : A±2%Metering for gas: 0.5-5 mmscfd,  Accuracy : 7%Power Supply: AC220V-240V/2KVANet Weight: 12tAppearance Dimension: L4.4m*W2.0m*H3.0mSoftware installed:YesSoftware language:EnglishMEASSUREconducting liquidreduplication0.25%Accuracy grade±0.5%Lining materialRubber, PTFE and other optionsElectrodesStainless steel, Hastelloy and other optionsspecific conductance≥5μs/cmFlow rate range0.3~12m/sFluid Temperature-25ºC~180ºCNominal pressure1.0MPa,1.6MPa,4.0MPaType of connectionFlangeFLANGE MATERIAL304SSBody material304SSOutput signal4-20mA,RS485,HART etc. ElectricalM20*1.5Protection gradeIP65,IP68Anti-explosiveOrdinary non-explosion-proof type, flameproof type (optional)Type of constructionOne body type, separate body typeElectric source220VAC,50HZ(24VDC)3.Description of metering principleThe MPFM can carry out the three-phase automatic metering of oil, gas and water production from tested well. It uses duplex-body tanks to measure liquid flow, a vortex meter for gas flow. And a water cut device is used to measure at interval time and calibrate water content of crude oil.  PLC automatic metering control cabinet controls automatically the process of metering and water cut measurement, collects data of each instrument and calculate and display the metering results.4. Product composition details  Detail list of the MPFM composition No.NameModelUnitNum.Notes1Duplex-body flow meterSTJ-V3500set1 2Vortex flowmeterDN50set1E+H3DPTDN50set4Emerson Rosemount4TIT644set1Emerson Rosemount 5PT3051set1Emerson Rosemount 6PLC control cabinet650*450*240/Ex/316Lset1Siemens6ES7-200Smart7Pressure gaugeY100piece3 8Temp. gaugePT100piece1 9Water-cut measuring deviceSF-2000Sset1 10Gate valveDN65piece10 11Ball valveDN65piece2 12Safety valveDN50piece2 13Manifolds & flangesDN65 /DN50set1 14Skid & protection4400*2000*200set1 /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
