Wheat Granules Ultrafine Powder Mill for Large Food Manufacturing Plant

Product DescriptionDust-free superfine  pulverizer dehydrated turmeric ginger  fruits  ultra-fine grinding machine for dried vegetables meat foodModelWKS-10WKS-20WKS-30WKS-60Capacity (kg/h)10-20020-40030-80050-1200Input size (mm)≤10≤12≤12≤12Output size (mesh)80-32080-45080-45080-450Total installation power (KW)11.522.54684.15Rotating speed (RPM)5800580038003200Installation dimension (mm)5410x1660x25005500x1800x31009000x2200x40009000x2700x5280Gross weight (kg)850120015003200WKS series of ultra-fine grinding unit composed of the host, auxiliary, electronic control box,  with wind selection, no screen, no mesh, uniform size, fineness of stepless adjustment.The production process is continuous.No temperature rise during grinding operation, suitable for a variety of heat-sensitive materials, particularly suitable for grinding fibrous material and material with a certain grease.Its comprehensive performance has reached the international advanced level, the machine is widely used in pharmaceutical, chemical, food, minerals (such as: traditional Chinese medicine., Food., Chemical., Health., Roots.), leaves, nuts, corn, pepper, wheat, garlic, star anise, cinnamon, dehydrated vegetables, hawthorn, dried ginger, garlic, sugar, saccharin, shrimp, pumpkin powder, seasoning).The machine has a crushing unit, a cyclone separator, a pulse dust box and an induced draft fan. The material enters the crushing chamber from the feeding hopper and is pulverized by the high-speed rotating hammer. You can adjust the distance between the classifying knife and the grading plate to achieve the required fineness, and the pulverized material enters by the centrifugal force and the effect of the induced draft fan. Powder is collected from the discharge mouth controlled by a discharge fan, and the dust enters the pulse dust box and is filtered through the filter cartridge for recycling.The whole machine is made of 304 stainless steel material, and there is no dust flying during the crushing process.ApplicationThe machine according to "GMP" standard design, the whole machine is made of 304 stainless steel, grinding process without dust flying. Its comprehensive performance has reached the international advanced level, the machine is widely used in pharmaceutical, chemical, food, minerals (such as: traditional Chinese medicine., Food., Chemical., Health., Roots.), leaves, nuts, corn, pepper, wheat, garlic, star anise, cinnamon, dehydrated vegetables, hawthorn, dried ginger, garlic, sugar, saccharin, shrimp, pumpkin powder, seasoning)Working PrincipleThe machine has crushed host, cyclone separator, pulse dust box induced draft fan and other components. Material from the hopper into the crushing chamber, through the high-speed rotating hammer crushing, crushing fineness adjustable grading knife and grading plate distance to achieve the required fineness, crushed good material by centrifugal force and induced draft fan into the Cyclone, then, through the off fan discharge, dust into the pulse dust box, filtered through the filter cartridge recycling. Packaging & ShippingOur AdvantagesFAQ/* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
