Automatic Hydraulic Swing Arm Clicker Press

Automatic Hydraulic Swing Arm Clicker  Press USE AND CHARACTER: The machine is suitable for cutting single layer or multiple layers of leather, plastic, paperboard, fabric and other materials by forming cutter. It is an ideal cutting device for shoemaking, luggage & baggage, clothing, automobile, artwork, packaging, electronics and other industries. 1.There are two types of cutting modes for selection. The first type is small pressure stepless regulation. The second type is that the cutting adopts intelligent pressure feedback design function without the need of setting cutting point. The height of die cutter has no influence on the cutting and ideal cutting effect can be obtained from each cutting point. TECHNICAL SPECIFICATION:Maximum cutting force            22T                    27TTravel adjustment range         0-70mm               0-100mmRange between the working tables       30-100mm              45-145mmSize of upper rocker     360×430mm             500*500mmSize of lower worktable      900×430mm          1000*500mmMotor power         1.1kW               1.5kwOverall dimension950×950×1350mm1050*1050*1600mmNet weight         900kgs              950kgsGross weight         1000kgs             1050mmAdjusting stroke                                  AutomaticElectronic supply50HZ 60HZ 220V ,380V ,440 V single phase three phase  or as optionalHydraulic oil                                  46# or 68#Automatic grade                                     ManualMachine color                         Red and green or as your optionalMachine logo                           CHAOYING or CustomizedOEM&ODM                                         WelcomeThe die cutter  :  Factory views :  Attending Fairs :  Customers' visiting  Delivery machines :    /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
