Product Description♦Auto broaching, Auto Nicking, Auto Bending, Lipping, Bridging, Flat Cutting, No-slot joint can do in one machine automatically♦Bridging Width: 5~15mm, Height: 5~22mm♦Double clamps system guarantee continuous and stable feeding.♦Material Specification: Height: 7~32mm, Thickness: 0.45~1.07mm♦Applications: High-end printing dies, blister packing dies, sticker dies, screen protector dies, cigarette packing dies, etc.♦Auto steel rule holder is optional for bender, the holder can take 5 different type of steel rule. Detailed PhotosTechnical ParametersMax bending angle100°Min arc radius of 180°R3.5Min arc radius of 90°R1.0Min cutting size1.0mmMin bending size1.5mmPower2.65KWSetting of bridgeHeight can be adjusted by software within 15-18mmWidth can be adjusted by software within 5-15mmOverall dimensions(L*W*H)2.6m*1.1m*1.7mWeight500kgMotor typePanasonic Servo MotorPower supply220V, 50/60HzAir compressor6-8kg/cm²Operation systemWindows 10Support languageChinese, EnglishSupport file formatDXF, AI, DWG, CDR etc.ComputerP4 ComputerMainframes19 inches LCD Our Advantages1. We have more than 15 years experience and technology.2. We have different models almost cover all sizes of steel rules.3. Our ball screws are C3 level from Taiwan, which is the highest standard using in the auto bending machines. The ball screw and guide rails forming the triangle, which is the most stable structure, ensure the stable and precise feeding length. 4. With special materials and many different technological processes, we are producing the most durable tools, usually it can reach to 300,000 times, while tools from some other companies only can use for about 100,000 times.5. There are few after sales problems with using the branded spare parts. With professional and complete production managing system before sending, the machines are working very well after arriving at customers' factory. Without after sales problem which will cause machine stop working, you will earn a lot more money and save time. Packaging & Shipping FAQ 1. Are you a factory or trading company?We are a factory with our own hardware and software engineer since 2008, with 15 years researching and experience. One of the earliest auto bending machine manufacturers from China. 2. How long is the warranty of your machine?We offer 1 year warranty from the date of shipment of the machines. 3. Can we change to our local language?So far we have simplified Chinese, English and German. Other languages can be customized if needed. 4. How can you guarantee quality?We have complete procedures of order preview, purchasing, mold management, assembling, internal quality audit, rejected spare parts control etc. 5. Can you send the service engineer to our company ?Yes, we can offer 3 days free training. And customers need to bear all costs during the training.6. How long is the production time of your machines?For the standard configuration, the production time is usually about 15 working days. For customized tools, it needs to be discussed. 7. How can I operate your machine? Is it hard to learn?It is easy to learn, we have complete videos and manual to teach you to operate the machines. If necessary, we can also send engineer to your factory, and customer need to bear all costs. /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
