High Precision CNC EDM Brass Wire Cutting Machine SWE85SL

1. Equipment Photo2. Equipment Features1. SWE36SL low speed brass wire cut machine a dopts Japanese STK technology and C-type high rigidity design, combined with high-strength main structure castings, to achieve high rigidity and thermal balance characteristics, ensuring the machine's ultra-high processing stability and accuracy.2. Use the linear motor made of Japanese technology, which features non-contact, frictionless, no kinetic energy conversion and brings outstanding performances that are unparalleled in general screw drive, such as high-speed movement, fast response, vibration free, high positioning accuracy, and no back gap thus no need of replacing screws, realizing the unimaginable high-precision cutting and long-term low-cost processing.3. Automatic threading function. Paired with automatic threading, it can effectively reduce working time and can be threaded directly at the disconnection point without the need for water or air assistance. Even if the cutting thickness is high (100mm), there can be a success rate of over 90% in automatic threading (the success rate decreases proportionally with the increase of thickness). The starting threading hole needs to be 0.05mm larger than the wire diameter. 4.  This machine plays an important role in the field of high-precision mould manufacture, shaped tool machining, hard-machined material and the machine of precise complex part.3. Equipment SpecificationNo.DescriptionUnitSpecification1X, Y and Z axis travelmm800*500*3002U V axis travel (U V)mm120X1203Max. Workpiece Dimensions (L×W×H)mm1200*800*2954Max. Workpiece Weightkg10005Max. Cutting Speedmm²/min2006Cutting accuracymm≤0.0057Surface roughnessμmRa≤0.48X Y feed ratemm/min8009Motor systemaxisLinear motor for X, Y axisAC Servo motor for U, V, Z axis10Max. Powerkw1011Wire Electrode DiametermmΦ0.15~Φ0.3 (Φ0.25)12Maximum wire feed speedmm/sec30013Line tensiongf300~250014Taper/Workpiece Heightmm/sec±20°/100mm(wide-angled nozzle, DA+DB=15mm)15Filtration capacity L76016Filtering method  Paper17Ion resin filter L1418Water quality control  Auto19Liquid temperature control Auto20Loop mode Power MOSFET Transistor21Maximum output current (A) 2522Dimensions (L×W×H)mm3600*3200*220023Net weight (include power box and water system)kg7200    4. Cutting Samples5. Packing ListNo.DescriptionQtyUnit1Machine body1set2Paper filter2pc3Diamond guides (0.26mm)2pc4Water cover2pc5Conductive block2pc6Diamond guide remove jig1set7Brass wireØ0.25mm5kg8Tools4pc9Spark vertical correction block1pc10Resin3L111Voltage regulator1pc12Grating ruler1pc13Water chiller1set  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
