Preform Injection Moulding Machine (ZS3280)

Preform injection moulding machine:This unit of our plastic injection molding machine composed of imported advanced hydraulic components. System pressure is controlled by proportional valve. According to users demand, a quick mold clamping device and fast-respond excellent control valves also can be fitted on the unit.CLAMPING-FEA designed double-toogle five-joint clamping machinery-High rigidity mould platen with enlarged space between tie bar, fit for larger scope of the moulds-Large moving die stroke with smooth & fast motion-Electrical & mechanical safety protection device-Automatic centralized lubrication system-Gear regulating the mould driven by oil motorINJECTION UNIT-Twin cylinder balanced injection system-High torque oil motor directly drives screw to complete the pre-injection-Specific screw and barrel designs are available for processing different material requirements to ensure the production quality-Multiple-stage control for pressure, speed, position to inject, keep pressure, charge materialCONTROL UNIT-It utilizes the plastic injection moulding machine special-purpose computer with rapid response, interactive interface-Regulate barrel temperature deviation automatically-Multiple-unit plastic moulding data memory system-Main electric components with world famous brand ensuring safety performance of electric devices-It real-timely monitors various actions and gives automatic warning for its defects-Clamp, injection, ejection action can choose linear displacement sensor for its controlHYDRAULIC UNIT-Main hydraulic components with world famous brand, ensuring stable quality of the machine-Low noise & rapid response oil pump system-Adopt the cooling water flow distributor, controlling the cooling temperature easily.ITEMUNITDATA ZS3280 CInjectionUnitScrew Diametermm70Screw L/D RatioL/D19.5Cylinder head  Volumecm 31070Shot Weightg1000Plastic Rate(PS)g/s62Injection Rate(PS)g/s350Injection PressureMpa135ClampingUnitClamping ForceKN3280Max mould Opening Strokemm585Mould Thickness(Min-Max)mm220-620Distance  Between Tie-Barsmm630×630Ejection ForceKN70Ejector Strokemm150OthersPump Motor PowerKW30Heating capacity of screw cylinderKW16.55Oil tank capacityL620Rated Pressure of Oil pumpMpa16Machine Dimensions (L*W*H)m6.33×1.59×2.2Machine WeightT11Mould Orientation Ring DiametermmΦ160H7Sphere Diameter of NozzlemmSR15    /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
