Bottle Preform Injection Molding Machine and Plastic Injection Mould Machine

Basic Info.Model NO.TLB-ITypePreform InjectionStructureHorizontalPlastic TypeThermoplasticPlasticizing WayScrew TypeClamping WayHydraulicAutomationAutomaticComputerizedComputerizedCertificationCE, ISO9001:2008Screw Diameter45mmInjection Weight260grClamping Force1300knSpace Between Tie Bar420*380mmMax. Mould Height450mmMini- Mould Height150mmMax. Pump Pressure16kmaPump Motor Power15kwTrademarktecreatTransport PackageWooden CaseSpecification40CBMOriginChinaHS Code8422301090Product DescriptionProduct DescriptionBottle Preform Injection Molding Machine / Machinery  Features:1) LCD computer control with big display screen2) Hydraulic double proportional valve3) Hard chrome plated high tensile strength steel tie bars4) Generous space for fitting large moulds5) Large opening stroke6) Two position transducers to control Clamping and Injection7) Four stages of injecting, independent velocity and pressure control8) Hydraulic mould height adjustment device9) Screw cold-start prevention device10) Melt decompression control11) Screw back pressure control12) Multiple hydraulic ejection13) Differential high speed clamping14) Centralized lubrication system15) Low pressure mould protection device16) Mechanical safety interlock17) Double electrical safety interlock18) Oil return filter19) Oil tank with inner stainless steel containerModelClamping force(KN)Mold thickness(mm)Tie-bars space(mm)Heat power(KW)Oil pump motor power(KW)Dimension(mm)Weight(KGS)KM-1000A1000150-400385x3507.6114300x1500x16003400KM-1320A1320150-420410x3758.2134500X1600X17003900KM-1400A1400150-420428X3868.2134800X1600X17004200KM-1650A1650170-440455X4258.2155000X1600X17005000KM-1800A1800180-470480X46011155300X1600X17505500KM-2050A2050190-470490X46411.6175400X1600X17506000KM-2300A2300200-510510X51011.618.55700X1800X20006500KM-2600A2600200-550554X55415.5256100X1700X18008000KM-3000A3000220-600580X58015.5256500X1800X18009000KM-3400A3400270-650640X64017.5306700X2000X190010800KM-3850A3850280-680680X68017.5307000X2200X200011500KM-4500A4500280-710720X72020.5377300X2300X240013800KM-4800A4800280-750750X72023.415+258300X2200X220016300KM-5200A5200290-780770X74028.118.5+258600X2200X225020000KM-5800A5800290-810800X77428.118.5+308750X2200X230021800KM-6500A6500350-860860X81937.125+309200X2200X240026000KM-7500A7500400-960961X96140.930+3710700X2300X270038000KM-8500A8500400-9801016X98042.537+3711000X2400X275045000KM-11000A11000500-11501230X11056312814000X2900X410063000KM-13000A13000600-14001350X128085.2516013200X3100X360076000Main parts list:NO.Parts NameBrandOrigin1Hydraulic MotorDAN DUNItaly-China2Hydraulic Oil PumpHIGH-TECHMade in Taiwan3Proportional Hydraulic ValveHUAYEMade in China4TransducerGefran Made in Italy5Sealing RingsHALLITEMade in USA6Reversal Hydraulic ValveSUNNYMade in USA7High-pressure VittaBarthezMade in Portugal 8ContactorLGMade in Korea9Air-break SwitchLGMade in Korea10ComputerTECHMATIONMade in Taiwan11Limit SwitchOMRONMade in China12Proximity SwitchSCHNEIDERMade in China
