Sb-10 Structural Durability Reasonable Price Elegant Design Rice Mill Machine

Sb-10 Structural Durability Reasonable Price Elegant Design Rice Mill MachineProduct Description:This model is a special small-scale equipment for paddy-processing .It is composed of feeding hopper paddy husking unit, separating unit for brown rice and chaff, milling unit and air jet blower etc. The paddy can finish the process of cleaning, husking, air-blowing selecting, and milling in succession. Then husk, chaff, rational layout, compact structure and little noise in operation. It is light and easy to operate with less power consumption and high productivity. The model can produce white rice with high purity above National standard 1, and with less chaff containing and less broken rice.Soit is a new type paddy-processing machine for the countryside.Technical parameter:ModelCapacity(kg/)Weight(kg)Dimension(cm)Power(kw)/Diesel engineSB-5500-60013065*67*1295.5kw or 8-10hpSB-10D900-120023071*72*17011 kw or 15hpSB-301100-150030076*94*17015kw or 20-24hpSB-501800-230056097*108*18822kw Structure and processing   Put paddy into hopper 1 through vibrating screen 2 to riddle gradual. Pull out hopper slide 3.The paddy screened slide over magnet unit to remove iron filings and are driven into between two rubber roller5 . Through feeding roller for husking. Paddy flow is controlled by flow controller4. Speed roller whirls in the reverse direction. It's line speed difference stands 3.14mps, ratio of whirling speed 1:130, while hulling rate is up to over 95% cleanse between rolls is regulated by rolling distance regulating system13. The cleanse is required between 0.5-1mm the odds and ends under huller are separated by air blowing. Chaff are blown out of the machine by chaff are machine. Blighted grain flow out from the blighted grain mouth7. While the blown rice are pushed into husking space for husking11. The polished rice are pushed out from rice draining mouth8. In the course of husking. High-pressure blower12 airblows uninterruptedly towards the hollow axis of rice machine, so as to decrease the temperature of rice in the husking space. The rice become clean and bright. Few of them are broken. Chaff goes easy and smooth. Degree of neatness of rice may be regulated with pressing weight of rice draining mouth9. Fine chaff is pushed out of machine through holes of turret screen10.Machines DisplayCHINA AID Machines in factory:Packing and loaing:Contact information:If you have interest in this sb rice milling machine, kindly please send us inquiry.  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
