Specification of D-R602 2cavity automatic blow moulding machine https://chinadoria.en.made-in-china.com/product-list-1.html1, Specifications of D-R602(2-cavity):1.1, Main machine dimension:1900(L)*1700(W)*1700(H)mm; Convyeor dimension: 1700(L)*1200(W)*1800(H)mm;1.2, Theoretical output: 2.5L,1500pcs/hour, 0.5L,2000pcs/hour. 1.3, The main structure is made of #63 channel steel, welded by A3 folding, the surface (blue as basic color) is treated with plastic ejection. the whole structure is delicate and durable.1.4, Stretch cylinder and pneumatic components adopt SMC brand1.5, Conveyor system adopts #45 steel, the surface is galvanized.1.6, Automatic preform-feeding for conveyor, it is easy to operate by only putting a certain quantities of preforms inside the feeding bucket. The movement of feeding,heating,blowing and finished bottle transferring is done automatically.1.7, Preforms are transferred to the heater through rotating and passing-one-by-one to ensure being heated evenly.1.8, PLC panel adopts Mitsubish to make the machine stable and reliable. 2. PICTURES OF D-R602 3. AUXILIARY EQUIPMENT:3.1,Air dryer(Model:OMK-1HNF);3.1.1 dimension:900*600*1100mm; 3.1.2, air flow:1.6N /min;3.1.3,working pressure:3.0MPa;3.1.4,inlet temperature:80ºC;3.1.5dew point temperature:2-10ºC;3.1.6,compressor power:0.6KW;3.1.7,refrigerant:R22;3.1.8 Dia of connecting pipe: ZG3/4;NOTE:when the device is in max use,the temp of inlet cooling water temp is 8-12ºC,outlet cooling water temp is 18ºC more or less;3.2, High pressure air compressor(VH-1.2/3.0).3.2.1,packing size:1600*850*1000mm; Size:1550*800*900mm;3.2.2,Motor power:15KW;3.2.3,weight:320KG;3.2.4,air flow:1.2M3/min;3.2.5,Max air pressure:3.0MPa;3.3, Low pressure air compressor(V-1.0/10)3.3.1,packing size:1500*730*1200mm; size:1465*680*1130mm;3.3.2,Motor power:7.5KW;3.3.3,weight:357KG;3.3.4,Air flow:1.0M3/min;3.3.5,Max air pressure:1.0MPa;3.4, T/C grade air filter3.4.1,rated air flow: 2Nm3/min;3.4.2,Max working pressure: 3.0MPa;3.4.3, inlet air temp≤50ºC;3.4.4, filter precision of T filter≤3μm; Filter precision of C filter≤1μm;3.4.5,weight: 2.3KG;3.5, 5HP water-cooled water chiller:3.5.1,dimension:910*520*900mm;3.5.2,compressor capacity:3.15KW;3.5.3,weight:130KG;3.5.4,refrigerating capacity:12.4KW;3.5.5,Pump capacity:0.5HP;3.5.6,Cold water flow:2.6M3/H;3.5.7,Voltage: 380V-415V/3P /50HZ;3.5.8,refrigerator medium: R224. SPARE PARTSNO.ItemTypeQtyRemark1voltage regulator2KG-F31pcs 2double way controlled siliconBTA412pcs 3low pressure solenoidAIRTAC 4V210-081pcs 4high pressure solenoidWH2315a1pcs 5light tube 6pcs 6fan160mm*160mm1pcs 7inner hexagonal spanner 1pcs 8spanner 1pcs 9foot base 4pcs 10Manual book 1pcs 11 5. About us:Taizhou Doria Plastic Equipment Co., Ltd. is located the town of plastic products and mould in China, which is one manufacturer owns special production teams, advanced production equipments and rich production experience.The main products are following: Automatic & semi-automatic blow moulding machine, PET preform, plastic injection machine, preform moulds, bottle moulds, commodity moulds and correlative products.Based on "Quality is first; Honor for the honest", we always continue development and innovation to witness the maturity of industrial chain of products and improve the quality of products continually. Untiring effort makes the products, especially for 5gallon blow moulding machine, 5gallon PET preform and commodity moulds are widely accepted by our customers. We have good market in South America, Africa, Asia, Europe, North America, and our many customers from Canada, Brazil, Thailand, Chile, Algeria etc.Meanwhile, the output of our main product automatic 5gallon blow moulding machine could achieve 600pcs/h which is the breakthrough of our company.Welcome everyone to visit us, we hope we will have good chance to cooperate!6. Location:No.362 Lingxiage VillageXicheng Street, HuangyanTaizhou, ZhejiangChina /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
