Bottle Blow Molding Machine (SD 2000-6)

Bottle Blow Molding Machine (SD 2000-6)Product Description: (1) Plastic Machine Function and characteristics   1. The blow molding machine is full automatic and has fast high effcientcy feeding system, adopting the sart wheel in the inverter motor to load embyro, to save the source.        2. Energy saving and high efficiency semi open style heating system can save more than 30%comparing with the same line.          3. Adopting Double Crank Arm Mechanical Sealing Mould, Bottle Die Likage Structure, matching with high pressure compensation sealing mould, to solve the problem of expanded mould and wide mould joint line.          4. Aopting Uk Norgren High Pressure Combination valve, big flowing, fast reaction, to improve unit production and save energy.     5. Standard Fittings Supply System to ensure the equipment run steadily and reduce the maintenance cost.        6. MMI design, Linear Structure, Simple Opration, Convenient and Fast Changing Mould.     7. Auto off Loading Bottle System, can be connected with conveyor(vacuum pipe)automaticly, matching with filling system. Technical Parameter Clamping mould systemModelSD2000-6Clamping force(Kg/f)60000Clamping stroke(mm)120Clamping stroke(mm)240Bottom mould stroke(mm)30Cavity pitch(mm)76.2Bottle parameterCavities Quantity(cavities)4Max.container volume0.6Max.neck diameter(mm)38Max.container diameter(mm)68Max.container height(mm)260Carriage unit (pcs)76Electronical systemTheortical output(pcs/h)4000-5000Perature increasement part(group)4Levels quantity of infraed lamps(level)8Total Power(Kw)41Heating power(Kw)38Air comprosser systemOperating pressure(kgf/cm²)8Low pressure Air consuming(ltr/mim)1500Blowing pressure(kgf/cm²)35High pressure air consuming(ltr/mim)6000Freeze drier systemOperating pressure(kgf/cm²)2-4Temperature(°C)10-12consuming(Kcal/hr)7600Flow rate(ltr/mim)45Water Chiller systemOperating pressure(kgf/cm²)2-4Temperature(°C)25consuming(Kcal/hr)45000Flow rate(ltr/mim)150Machine dimensionSize(L*W*H)(mm)2900*2150*2000Weight (ton)4.5  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
