300kg/H Pet Bottle Plastic Washing Recycling Line

Product Description300kg/h Pet Bottle Plastic Washing Recycling LineRaw material & formulationPET bottlesProduction processesConveyor -- Label separator -- Sorting --crusher-- washing -- dehydrator -- drying -- Label separator - collect.Melt capacity200-300kg/hPicture of final productPET flakes, Length: 40-60mm for soft materialWarehouse/WorkshopConstruction of foundations, construction works, earthworks, and wall works;Supply of cranes, fork-lifts or other lifting equipment; Mounting materials and tools;Dimension (M): 55(Length)×10(width)×5.5(Height)Power supplySupply voltage: 3×380V+N+PE;Voltage tolerance: +5%/-5%;Control voltage: 24VDC+220VAC;Frequency: 50HZ+-2%Wire/cables/water hose:Wires/cables: from power supply to control cabinet of this production line and all electrical cables from control cabinet to each machine;Water hose: supply water to machines and pools.Cooling waterWithout dissolved or suspended minerals as phosphor,sulphur,iron,etc.Ancillary staff3-4 Persons  Features1. We have the Bale opening and feeding system which and equally feeding the material save labor;2. You can use the manually sorting system to selecting out different color bottles and non-PET material;3. Metal detector is optional for you which used to take out any kind of metal from the PET bottles;4. Specially designed PET bottle Crusher Machine can easily get high output and with water doing wet griding can extension the blades use life, reduce the dust generation;5. High speed Dewatering machine and the drying system can guarantee the final PET flakes moisture
