Myk1224 High Quality Precision CNC Surface Grinder Grinding Machine

MYK1224 High Quality Precision CNC Surface Grinder Grinding Machine Product DescriptionCharacteristics:1. The structure of the machine tool is reasonable, large machine tool bed weight, excellent stability, using the cross saddle structure, good rigidity, has the advantages of beautiful appearance and convenient operation.2. Horizontal movement of working table (before and after) by servo motor drive, precision ball screw drive, to ensure accuracy, accurate positioning, in accordance with the procedures of automatic feeding, automatically and fast forward and rewind functions.3. Working table vertical (or so) movement, the use of a V a flat guide, and the artificial precision shovel flowers, the use of hydraulic transmission, stable operation.4. The grinding head up and down movement driven by a servo motor, which can achieve precise positioning accuracy, automatic feed and fast lifting function.5. The Guangzhou CNC system GSK96 and two axis NC, according to the actual processing conditions free programming, with pulse wheel, X and Z axis feed can be free to switch freely.6. Machine adopts full enclosed casing, can completely cover the whole of the working area, effectively prevent the splash of the cooling liquid and iron filings, and according to the requirements of clients connected ceiling spray dust removal device. (optional)7. The characteristics of the CNC grinding machine is realize three-axis full automation, the second axis plane grinder while reducing the labor intensity of the operator, but also a single stand-alone operation, three axis automatic surface grinder, a worker can be 3 - 5 machines are operating at the same time, greatly reduce the labor cost, especially when the batch processing, the benefit is more remarkable.Application:Applicable to all kinds of processing machinery, auto parts, fixture, magnetic steel, mould parts processing industry.The machine tool can be made of grinding steel, iron, ceramics and non-ferrous metal parts.Main technical specifications:SpecificationsUnitsMYK1224workbenchWorktable size (L * W)mm600x300Max. travel of  tablemm650x320Table T slot (slot number x slot width)mm1x14Grinding headSpecial grinding wheel size (o. d * w * i. d.)mmØ300×30×Ø76.2Distance spindle center line to working tablemm520Grinding wheel speedr/min1450The amount of feedTable longitudinal (left and right) speedm/min3-25Table transverse (front and rear) feed handwheel feedm/min0.5-15Grinding head(up and down)automatic feedmm0.005-0.05Grinding head up and down is fast lifting speed (approximate value)m/min0.6Hydraulic systemHydraulic motorKW2.2working pressureMPa4Fuel tank capacityL100Maximum flow rateL/min20Motor powerSpindle motorkw3Cooling motorW90Elevator servo motorkw1.0Front and rear servo motorkw1.0working accuracyThe process surface of the base  level of the parallel degreemm300:0.005Surface roughnessμmRa0.32Machine weightNet weightkg1500Gross weightkg1600Suction cup specificationmm600x300External size (L * w * h)mm2800×1600×1800Packing size (L * w * h)mm2900×1700×2000  Company Profile  CertificationsFAQ1: Where is your company A: Our company is located in Tengzhou City, Shandong Province.2: What about your warranty?A: Warranty is one year. During warranty time, if the parts are damaged because of Nonhuman factors, we will send new replaced parts for free3: How do you offer after-sale service?A: We usually offer technical support online by wechat or whatsapp. Customer describe the problems and send videos and pictures, our technician will help to solve the problems4. What is your standard package? A: Our package is export standard plywood case with pallet.5: What's the Payment Terms? A: T/T, 30% initial payment when order, 70% balance payment before shipment; 6: What's the MOQ? A: 1 set./* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
