QC11y Hydraulic Guillotine Shearing MachinePART 1---Products description Features:1.The frame and blade's holder adopt overall welding structure , vibrating to elimate stress, which can keep good accuracy.2.It adopts three-point support ball screw guideway, keeping good accuracy, which can improve the quality of shearing.3.The handwheel can adjust the gap between blades quickly, exactly and easily .4.The rectangular blade, whose four cutting edge can be used, with a long service life. The shear angle could be adjusted to reduce the the distortion of working piece.5.The upper tool post adopts medial structure, which is easy to down ramp and can improve the accuracy of workpiece, adjusting the travel of upper tool post steplessly.Parameter:ModelThroat DepthBack Gauge RangeShear AngleStrokesMain motorOverall DimensionWeight(mm)(mm) (min-1)(KW)(mm)(kg)4×20001006001º 30º≥185.52640×1560×165040006×25001006001º 30º≥147.53160×1610×165052008×32001006001º 30º≥10113860×1610×1650640010×40001006002º≥7154800×2000×21501250012×50001008002º≥618.55820×2450×24001800016×60001008002º≥5306850×2650×26003500020×25001008002.5º≥6303420×2150×21001200025×320010010003º≥5374150×2600×26002300025×400010010003º≥5454890×2800×28002600032×25001008003.5º≥5453480×2600×26002100032×320010010003.5º≥5454180×2800×280027000 PART 2---Our Service1.Free replacing parts available in the warranty period.Cost price replacing parts available beyond the warranty period. 2. Quick action and reply for the technical questions at any time in the whole life of the machine.3. Overseas after service center available in some region.4. Engineer overseas service available on the requirement of customer(relative cost born by customer). Part 3---Company Information "TIMEWAY MACHINE" is a registered Chinese business business located in Zhengzhou city, in the center of China, and has been opearting in the machinery industry for many years. Our factory is the joint-stock enterprise, founded in 1946, has 50 years of machine tool manufacturing history.Occupies more than 500acres, built a foundary, machining, heat treatment, assembly, quality inspection, painting, logistics and other advanced production lines. Our product mainly cover lathes, Milling, Drilling, Gringding, Sawing, Shaping/Slotting and related accessories&tools, etc. /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
