Customizable Flat Processing Equipment for Pneumatic Systems

  Product DescriptionWelcome to Changzhou Faer Lin Precision Machinery Co., Ltd.Introducing our latest product: the Sample Customization Flat Processing and Stacking Production Equipment for Pneumatic System. This state-of-the-art machine is designed to revolutionize your production line and enhance your carbon fiber processing capabilities.Product Features:Front-end conveyor for seamless material handlingUnwinding device with length setting for precise controlCutting device for accurate and efficient processingMilling inclined plane processing host for superior resultsCutting angle processing host for added versatilityBack-end conveying and stacking system for easy outputHow It Works:Once the carbon fiber board is extruded into a roll, our front-end conveyor smoothly transports it to the milling inclined plane equipment, following your set processing requirements. The cutting and angle processing hosts ensure precise and high-quality results. The back-end conveyor then efficiently outputs the processed carbon fiber board, while our transport truss manipulator safely transports it to your stacking platform.Provided by Party A:Conveyor frameUnwinding deviceUnwinding length setting deviceCutting deviceStacking platformProduct Specifications:Product Line: Carbon Fiber MachineAutomation Level: OtherAfter-Sales Service: OtherUpgrade your production line with our Sample Customization Flat Processing and Stacking Production Equipment for Pneumatic System. Experience enhanced efficiency, accuracy, and versatility in your carbon fiber processing. Contact us today to learn more!  Product ParametersMilling inclined plane unitSerial NoProjectSpecifications1Stroke of each axis (machine part)X:1100mmZ1,Z2:300mm2X. Z-axis transmissionFeed motor: AC servo motorX-direction lead screw: φ 50X10mmZ-direction screw rod diameter: Φ 50X10mm3Fast moving speedX:6000mm/min, Z:6000mm/min4Working feed speedX and Z axes: 1-5000 mm/min5Machine tool accuracyPositioning accuracyX:0.03mm/1000mmZ:0.02mm/total length6CNC systemTaiwan's new generation system7Spindle power7.5Kw (servo)8Spindle speed200-3000rpm9Air Pressure0.6MPa10Overall dimensions of main engine (L * W * H)About 2800 mm * 1000 mm * 2300 mmCutting bevel unitCutting bevel unitSerial NoProjectSpecifications1Stroke of each axis (machine part)X: 1600mm (angle 1:5)Y: 350mm (angle 1:5)Z: 300mm2X,Z-axis transmissionFeed motor: AC servo motorX-direction lead screw: 50X10mmY-direction lead screw: Φ 40X10mmZ-direction screw rod diameter: Φ 50X10mm3Fast moving speedX/Y/Z:6000mm/min4Working feed speedX and Z axes: 1-5000 mm/min5Machine tool accuracyPositioning accuracyX:0.03mm/1000mmY:0.02mm/total lengthZ:0.02mm/total length6CNC systemTaiwan's new generation system7Main motor power5Kw (servo)8Spindle speed200-3000rpm Tool sizeΦ300X3.5Carbide saw disk9Air Pressure0.6MPa10Overall dimensions of main engine (L * W * H)2850X2000X2100Conveyor carrier unitSerial NoProjectSpecifications1Roller conveyorMaterial: aluminum profile80m long, segmented splicing structure2X-axis clamping moving unitQuantity: 2 setsTravel ≥ 80mPneumatic clamping and jacking are adopted, and the clamping force is adjustable.3Side positioning devicePositioning accuracy ± 2mm4X axis feed speedAdjustable speed: 0-20m5X axial positioning accuracy±2mmManipulator stacking unitSerial NoProjectSpecifications1Travel of each axis of manipulatorY-axis stroke: 1250mmZ-axis stroke: 300mm. (With 900 height as the reference, the upward stroke can be 250mm, and the downward stroke can be 50mm)2Applicable plate specificationThe width is 150mm, and the width can be expanded in the later stage: 105-210mm.Plate length: 80 m.Plate thickness: 5mm.3Motion speed of each axis10-10000mm/min4Sheet stacking accuracyUpper and lower layer error ± 2mm, left and right error ± 2.5mm, end error ± 5mm5Synchronous accuracy of each axis of truss±1mm6Repetition accuracy of each axis of truss±1mm  Detailed Photos   After Sales ServiceCompany Profile1.General Information Welcome to Changzhou Faer Lin Precision Machinery Co., Ltd., located in the beautiful Bingjiang economic development zone in Changzhou, Jiangsu, China. Our company is dedicated to providing high-quality and reliable automatic line and CNC special machines with exceptional accuracy and efficiency. Over the past five years, our business has experienced tremendous growth, with sales revenue increasing from RMB 5 million in 2012 to approximately RMB 50 million in 2016. This remarkable achievement has led to our recognition as a Jiangsu high-technology enterprise in 2015, thanks to our impressive portfolio of 22 high-technology products and over 20 patented technologies. At Faer Lin, we pride ourselves on our commitment to excellence. Our team consists of exceptional talents who have more than ten years of experience in state-owned company management, product design, sales, R&D, manufacturing processes, and production. With their expertise, we have the capability to develop and manufacture first-cl
