APM0605 FINCM Metal CNC Angle Iron Hydraulic Punching Marking Shear Machine

Product DescriptionAPM0605 FINCM CNC Angle Line  Automatic Hydraulic Shearing  Marking Punching Machine ToolIt is mainly used for customers to manufacture angle steel components, complete typing, punching, fixed length cutting on anglesteel. Simple operation, high production efficiency.Technical specification of APM0908:ModelAPM0605 Angle Size35x35x3mm~56x56x6mm(Q235) Max. workpiece length8m Max. punching capacityΦ22mm Nominal punching force150KN Nominal marking force540KNNominal cutting force300KNNo. of character group4No. of character in each character group18Character size14x10x19mmNo. of punch on each side3Max. feeding speed80m/minNo. of CNC axes3Overall size20x4x2.2m Total power13KW Machine weightApprox. 10000kg The finished angle conveyor is rotated to one side by pneumatic power, the max. length of finished angle is 12m.There are four sets of transverse conveyor, infeed automatically and intermittently.Angle feeding Speed: 40m/min, the effiency is about 1000 holes/hourType of programming: keyboard input, USB interface input, floppy disc input  List of the Key Outsourced Components:NoNameBrandManufacture1AC servo motorDeltaTaiwan China2PLCDeltaTaiwan China3Electromagnetic valveAtosItaly4Relief valveJUSTMARKTaiwan China5Double vane pumpAlbertUSA6Air valveAirtacTaiwan China7CylinderAirtacTaiwan China8ComputerLenovoChina       Company Profile  Shandong FIN CNC MACHINE CO., LTD. is always focusing on our ultimate goal - to secure and increase our customer's productivity - has made us the leader in China market in the manufacture of machines for processing angle bar, beam channel profiles, steel plates, tubesheet and flanges, mainly serving for fabricating iron towers, steel structure, heat exchangers, boilers, bridges, and trucks.Strong R & D center with 30 engineers team, 24 years of experience from year 1997, 280 staff, plant area about 270,000 sqm., very harsh quality control of every component and the whole machine, about 40 million US dollars sales turnover per year.  FIN CNC machines' market share in China is around 70% and exported to 50+ countries across globe market. All top ranked tower manufacturers, steel structure fabricators and power station makers, bridge/railway manufacturers, truck makers are our clients.  Main products: CNC Angle Line, CNC Beam Drilling Sawing Machine, CNC Plate Drilling Machine, CNC Rail Processing Machine, CNC Tubesheet Flange Drilling Machine, Truck beam plate punching machine, etc..One measure of the outstanding quality of our machines is their longevity: many FIN machines have been in operation for more than 17 years! Many clients are continually placing repeated orders which verified well our machines' perfect quality and reliable performance.The company drafted many China national standards for CNC angle line machine and CNC beam drilling sawing machine and CNC plate drilling machine.   Cooperative Supplier    Product Process Control      Customer Praise:    Sale Networks      Customer praise:   FAQ:1. When can you arrange shipment?For machines available in stock, the shipment can be arranged within 15 days after getting advance payment or L/C;For machines non available in stock, the shipment can be arranged with 60 days after getting advance payment or L/C.2. What can you do if my machines have problems?1) We can send you free components if machines are in warranty period;2) 24 hours service on line;3) We can assign our engineers to serve you if you want.3. Do you provide machine operation training?Yes. We can send professional engineers to the working site for machine's installation, commissioning and operation training.4. Which machine model shall I choose when I purchase from you?Please share us your material size and your processing request, then we will recommend our machine most suitable and most cost effective for your work demand.5. What's your machine's market share in China?Our market share in China is about 70%+, and we've exported to 50+ countries across the globe market, since year 1998.   /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
