Non-Excavation Machinery 12000kn Xz12000 Horizontal Directional Drilling Rig

Horizontal directional drilling rigXZ12000 Cummins QSZ13-C550 Power rating(kW/r/min) 4×410/1900 Max pull/thrust force(kN) 12000   XZ12000 Horizontal Directional Drilling Rig PRODUCT FEATUREHorizontal directional drilling rig (English abbreviation: HDD) is a kind of construction machinery that lays a variety of underground public facilities (pipelines, cables, etc.) under the condition of not excavating the surface, which is widely used in water supply, electricity, telecommunications, natural gas, gas, oil and other flexible pipeline laying facilities, it is suitable for sand, clay, and other ground conditions, not suitable for high groundwater levels and pebble formations, most of China's non-hard rock areas can be constructed.Construction characteristics of horizontal directional drilling 1. The directional drilling crossing construction has the effect that it will not obstruct traffic, will not damage green spaces, vegetation and buildings, and will not affect the normal life and work order of residents. 2. Modern crossing equipment has high crossing accuracy, easy to adjust the laying direction and burial depth. 3. The buried depth of urban pipe networks generally reaches less than three meters, and when crossing rivers, they are generally buried 9-18 meters under the riverbed. 4. No water or underwater operations, no impact on river navigation, no damage to the dikes and riverbed structures on both sides of the river. 5. The speed of entering and exiting the site is fast, and the construction site can be flexibly adjusted. 6. Pre-reaming is to expand the hole back to the expected diameter according to 1.3~1.5 times the size of the pipe diameter step by step under the condition that the geological situation and underground pipeline detection or survey are clear.  XZ12000 Horizontal Directional Drilling Rig Performance Characteristics 1. Digital instrument, automatically display the actual torque, push and pull force and other main construction parameters in construction, simple operation; Electronic sensing technology is responsive, can timely feedback instantaneous overload, reliable protection of drilling rigs; 2. PE pipeline elastic balance release technology, effectively prevent equipment damage caused by the reaction force of the dragging pipeline, and improve the reliability of equipment construction; 3. Overload protection technology, drilling rig rotation torque, push and pull force and vice clamping force can be adjusted and adopt digital pressure regulation technology, easy and simple adjustment, can be accurately preset. Non-Excavation Machinery 12000KN XZ12000 Horizontal Directional Drilling RigThe digital instrument automatically displays main construction parameters such as actual torque and push-pull force during construction, and the operation is simple. The electronic sensing technology is sensitive, which can timely show instantaneous overload, reliably protecting the machine.The sliding of drill frame depends on the push and pull of hydraulic cylinder, combined with the front rocker arm, the adjustment of penetration angle is simple, convenient and safe.Dual-power system is adopted, in which either engine can complete all the work; combined with the proprietary speed regulation technology under multiple working conditions and multi-gear control technology of rotation and push-pull, the machine has a wide application range. In the case of small pore diameter construction, it can work with only one engine, which lowers the fuel consumption and construction cost.It adopts advanced control technologies such as load-sensitive control and electric-hydraulic proportional control, which can realize energy saving and consumption reduction as well as flexible and comfortable operation. The key hydraulic, electrical and transmission components are all of international first-class brands with reliable quality.PARAMETERS   ItemUnitParameterEngine  Model-Cummins QSZ13-C550Power ratingkW/r/min3×410/1900Thruet-Pull  Max pull/thrust forcekN12000Max pull/thrust speeedm/min32Rotation  TorqueN·m260000Max spindle speedr/min100Mud pump  Max fiow rateL/mincircumscribedMax pressureMPa20Pipe  Diameter×Lengthmm×mφ219/φ254×9.6Loader Crane  Lifting weightt10Loading capacityt·m25Max inclination angle°16Max backreamer diametermmφ2500Weightt135Diamension(L×W×H)mm20000×3400×4700Power Station dimensionmm9117×2438×2591Power Station weightt26.5   Pictures show/* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
