Grinding Machine Multifunctional Micro Surface Grinder Countertop Micro Grinder

 Grinding machine Multifunctional Micro Surface Grinder Countertop Micro GrinderThe equipment is novel in design and easy to operate. General technicians can quickly and proficiently master the operation. The product to be ground is flat on the work surface through the magnetic attraction platform and fixed firmly, and the spindle motor of the grinder is turned on. Move the grinding wheel height up and down according to the size requirements, and push the grinding wheel left and right. Motor for grinding.Product parametersEquipment dimensions: 390*360*580 Equipment working voltage: 380V (220 optional)Workbench size: 70*150 Magnetic table top Grinding wheel lift size: 100 Spindle speed: 2800R/min Machine power: 1kwGrinding wheel size: cup wheel inner hole 20Gross weight of machine: 50kgLighting Configuration: High Brightness LED Lead Screw Lifting Accuracy: 7umInstructions1. Install the equipment grinding wheel on the motor shaft, and tighten the grinding wheel screw with a torque of 25-30NM.2. Fix the protective cover on the housing of the grinding wheel motor to prevent the dust from affecting the sight during the grinding process of the grinding wheel. The turning of the grinding wheel is counterclockwise. If the direction is not correct, the phase sequence of the input power can be changed.3. If it is found that the rough surface of the grinding wheel affects the grinding accuracy, you can use a diamond grinding wheel pen to be adsorbed on the magnetic table to correct the end face of the grinding wheel. During the correction process, the height of the grinding wheel is slowly lowered for repeated grinding (generally 5-10 times of grinding can be done). ).4. When grinding small parts, pay attention to observe whether the fixing strength is sufficient. If the parts are too small and the fixing suction is not enough, a thin iron sheet with an appropriate suction cup can be used as auxiliary fixing.5. Slowly reduce the height of the grinding wheel during the grinding process, and observe the grinding sparks to judge the feed rate.6. The thickness can be measured when the grinding wheel grinds the product for the first time, and then according to the required size, rotate the hand wheel counterclockwise to reduce the height of the grinding wheel for sequential grinding.  Company ProfileNanyang NanTai Experimental Equipment Co.,Ltd is a joint-stock enterprise that produces common rail test bench, traditional dieselfuel injection pump test bench, Nozzle Tester, and sells spares parts for repairing variety of electronic diesel injection systemsto serve the automobile aftermarket all over the world.The company pursues high standard manufacturing and qualified products. All the products have passed the quality systemcertification of ISO9001:2008 & CE certificate and entered European market. Depending on the stable and lasting capabilities, ourproducts are well known to international market such as Russia, Mongolia, Bulgaria ,Albania, Argentina, South Africa, Germany,Romania, Ukraine, Haiti, Iraq, Britain, Brazil, Malaysia and etcCertificationsPackaging & ShippingFAQQ: Are you trading company or manufacturer ?A: We are test bench assembling factory. We have had test bench for 20 years.Q: How long is your delivery time?A: Generally it is 5-10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according toquantity.Q: What is your terms of payment ?A: Payment=1000USD, 30% T/T in advance ,balance before shippment.Q: How about the use of maintenance technology and equipment ?A:We have free training about test bench,injector and pump maintenance.Q: Why should I choose your product?A: We can provide you the best quality and the most competitive price ,and we have our own engineer, if you have any requirementsyou can contact us directly./* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
