64inch Ball Valve Girnding Machine for Big Size Balls

Introduction of CAMINIX Ball Grinding MachineCAMINIX CNC Ball Valve Grinding Machine is designed ,developed and manufactured for precise grinding of the sphere ( Balls) of the ball valves,With range of DN15-DN1600 1/2''-60'' various kinds of balls with materials of carbon steel,stainless steel,alloy steel,Monel,Tungsten Carbide coating, etc. All of the machines are equipped with latest generation of FANUC brand control system, to accomplish the ball roundness of 0.01mm and roughness Ra0.2.CNC BALL VALVE GRINDING MACHINE QM2280 DATA SHEET   ItemUnitModel: QM2280Max Ball Grinding DiametermmΦ1500-φ2400Max Ball Bore Diameter(≈)Inch40″­­-64″Distance between top central line to the tablemm1400Max Ball WeightKg18000The power of Main Spindle Motorkw75Main Spindle Rotating Speed RangeRpm100~600Headstock PowerKW37Headstock Rotating Speed RangeRpm6-50The Journey of the X/Z directionmm1100/900The adjusting range of the tailstockmm900Two Apex Center Distance Rangemm/Head/tail stock apex Cylinder X/Z axis Positioning Accruacymm0.02X/Z axis Repearabilitymm0.01Ball Roughness Ra0.4Ball Roundnessmm0.03Approx. Dimension(LxWxH)mm11000×8000×3800Approx Net WeightKg90000Caminix reserve the rights to change the specification according to actual production. WORK PIECE SAMPLE Appliable Ball Types: As per Ball Materials:      Casting Valve Balls, Forged Valve Balls, As per Ball Structure :     Hollow Valve Balls, Solid Valve Balls,As per Ball Design:          Floating Valve Balls, Trunnion Valve Balls, Stem Valve Balls,V Port Valve Balls (Segement Balls),                                            T Port Valve Balls, L Port Valve Balls, F Port Valve Balls, X-Port Valve Balls,                                            L-STEM, X-STEM, T-STEM, Double Slot T Port, Special Slot, F Port Three Ways,                                            Three Way Valve Balls, Hexangular Valve Balls, Hemi Valve Balls,                                            Plate Balls, Metal Seat Valve Balls and Seats,AS per coating materials : TCC Valve Ball, HVOF Valve Ball, Chrome Valve Ball, Stetllite Valve Ball Grinding Ball Size: 1/2''-60'' Class 150~Class 2500 PN10-PN420 Base Material:  Carbon Steel, Stainless Steel, Alloy Steel                          ASTM A105, ASTM A350 LF2, ASTM A182 F304, ASTM A182 F316,ASTM A182 F304L, ASTM A182 F316L,ASTM A182 F6A,                           ASTM A182 F51, ASTM A182 F53,ASTM A564 630(17-4PH) Inconel 625,Inconel 690,Inconel 617,Inconel 718,Model 1400 etcCoating Materials:  Coating: Nitridation,Nickel Plate,Chrome Plating,HVOF Tungsten Carbide,Spray Stellite,Spray Nickel Alloy,Spray Cobalt Alloy NI60,NI55 Inconel  etc   If you need any more information, please feel free to contact Caminix.  Caminix CNC Machinery (Zhejiang)Co.,Ltd Address: Building 38, 1st Xu'an Industrial Park,Gaohu Town,Qingtian,Lishui city,Zhejiang,China Please contact us by email or wechat or whatsapp. Thanks.FAQ 1. Are you the manufacturer ?    Yes, we are the manufacturer with more than 10 years' experiences in the valve grinding machine & Testing equipments design & development and manufacture. 2. What is your company  brand?    We have CAMINIX , CMXCNC, DORY, for the different products line.3. What is your mininal order qty?    We are manufacture the machines for the industry, the mininal order is one . 4. What is your delivery time?    Our delivery time depends on the machine model, please contact us when inquiry for detailed information. 5. What is your payment term ?    Our standard payment is 50% advance payment by T/T after order confirmation, balance payment 50% paid by T/T before shipment. 6. What is your machine warranty ?    Our machines are guaranteed by 12 months after date of shipment. 7. Can you do OEM services ?    Yes, we can , we can use your logo, please specify when order. 8. Do you have any references in overseas?    Yes, we have. We have exported many machines to overseas market, There are some wellknow company like Emerson, Praxair  etc.      Please contact us for detailed information. /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
