Heavy Universal Cylindrical Grinding Machine Grinder ME1432B M1440  M1450

The Universal Cylindrical Grinding Machine is designed for grinding cylindrical or conical external surface with accuracy of IT5 and IT6. It is most suitable for tooling or repair workshop in small batch production. The longitudinal travel of worktable is controlled steplessly by hydraulic system or by handwheeel. The infeed of wheelhead is carried out by hydraulic automatic periodic feed and also by handwheel. The rapid approach and withdrawal of wheelhead retracting of tailstock center lubrication of slideway and lead-screw are all hydraulically controlled.                                                         M1420  M1432  M1440  Specifications                                                                ItemM1420M1432BM1440OD grinding diameterΦ8-200Φ8-320mmΦ150-400mmID grinding diameterΦ13-100Φ30-100mmΦ16-125mmCenter height135mm180mm220mmWorkhead spindle speed50Hz:25-380 rpm stepless  Max. Travel of table650mm/950mm1100/1600/2100/3100mm1000/1500mmHydraulic transverse speeds0.1-4  Max. Workpiece weight50kg150kg150kgGrinding length External/Internal500/125mm1000,1500,2000,3000mm/150mm Swivel range of grinding wheel-5~+90°  External wheel sizeMax.Φ400x50x203mmMin.Φ280x50x203mm      Φ400x50x203mm      Φ500x50x203mm Internal wheel spindle rotating speed16000rpm 10000/20000rpmWorkhead and tailstock centerMorse No.4Morse No.4Morse No.4Total motor power5.625kW9kW9kW   FAQ 1. MOQ   1 set . 2. DELIVERY TIME       It depends on the machine and model you choose. Mostly 2 months - 4months. All      machines are 100% new and not used.  3.  PAYMENT TERM    T/T 30% down payment when order, 70% balance payment before shipment.4. WARRANTY PERIOD    13 months from the date of B/L, during the warranty period, daily damage parts will be supplied  freely,  the after sale service will be done by dealers . After warranty period, the spare parts will be   supplied at factory price.    /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
