Marble Gantry Grinder Grinding Marble Workpiece

The name of the machine: CNC shaping grinding machineMachine specifications:Crm-315Machine images:  CRM-315 CNC blade grinder is the leading variety developed by our company itself. It is designed for the screw rotor manufacturing industry. Supporting the knife grinding machine tool. Designed (milling molding tool) The blade mill uses a program to simultaneously sharpen the front and rear corners of all the blades on the blade. The machine tool uses the universal CNC system blade mill special version software.                                  Structure and main technical parameters of CRM315I. Structural characteristics of the machine tool: 1. The machine tool adopts the gantry structure (fixed beam moving platform), and the bedside box and tail seat are installed on the worktable to support the knife body. The workbench is reciprocated through the ball-screw bars. 2. The machine tool adopts the ball line guide rail, with high positioning accuracy, fast moving reaction, low speed feed and good crawling stability. 3. Machine rail lubrication is lubrby centralized intermittent special lubrication pump and timely. 4. The feed shaft [Z, X and Y axis] adopts high precision ball wire directly driven by wide servo motor, with high transmission accuracy and good positioning accuracy. 5. The bedside C-axis adopts broad servo motor direct connection and high-precision worm worm worm (this worm worm is the gap worm worm, and the side gap can be adjusted and adjusted). 6. The grinding wheel spindle is driven by the electric spindle to achieve the infinite variable speed. 7. The machine tool is equipped with a high-pressure water pump, which realizes the cooling effect through forced cooling during processing. 8. The electrical components in the electrical control cabinet of the machine tools all adopt Delixi brand. 9. The machine tool is equipped with a machine tool protective cover. projectcontentunitMachine tool useGrinding cutting tool The length of the lathe bed1300mmBed width1200mmCutter diameterΦ150 -Φ315mmGrinding tool material  Alloy tool superhard tool steel, etc Grinding head spindle power550(reference)W Grinding head spindle speed2500-2800r/minGrinding wheel material CBN Servo control shaft number ool rotation (C axis)  Beam (Y-axis)   Sliding platform down (Z axis)  Table (X axis)  Numerical control systemWide number Crm-260 CNC shaping grinding machine  CNC rotor milling machine  Numerical control cyclone milling machine  CNC spline milling machine  CNC five axis precision milling machine  CNC gantry grinding machine CNC screw milling machine Contact Person:  Candy HuHello, thanks for visiting Kangnuo cnc machine tool manufacturering Co. Ltd. My name is Candy Hu , please send me your intrested Machine ,and your workpiece diameter range ,drawings are welcomed and would be replied at the first time.>>>>>>>>>>>>>>>>>>>>>>>>>>you could also find me at 0086182&&3379&&8502 (please remove &) hope we could cooperate in the near future!   /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
