China New 20m Electric Ariel Working Platform Za20je Boom Lifts

Articulating boom lift ZA20JE- Zoomlion  Zoomlion articulating boom lifts offer high capacity, great outreach and easy maintenance. The larger work envelope provides you with access to those hard-to-reach places. Our line of diesel articulating boom lifts help keep productivity high.   ZA14J features large capacity, high reliability, accurate control and great performance. It has the strength to handle loads up to 300 kg. Our hydraulic system with multi-way valve for precise flow distribution and high weighing precision of ≤±5kg guarantee efficient performance. Strong and energy-saving power system with professional off-road chassis let you handle complex road conditions. On-board diagnosis, lubrication-free design, and swing-out engine tray make maintenance more convenient and reduce the total cost.Electric Articulating Boom LiftsComply with CE/ANSI/GB StandardModel ZA20JE GBZA20JE CESizeWork Height21.45m21.50mPlatform Height19.45m19.50mHorizontal Outreach11.45m11.45mUp and Over Height8.25m8.30mA - Stowed Length8.72m8.72mB - Stowed Width2.49m2.49mC - Stowed Height2.52m2.56mD - Platform Length1.83m1.83mE - Platform Width0.76m0.76mF - Wheelbase2.52m2.52mG - Ground Clearance330mm375mmPerformancePlatform Capacity250kg250kgDrive Speed6.1km/h6.1km/hGradeability45%45%Axles Oscillation200mm200mmTurning Radius (Inside)2.78m2.78mTurning Radius (Outside)5.49m5.49mSwing400° non-continuous360° continuousPlatform Rotation±90°±90°H-Tail Swing0.6m0.6mMax. Working Slope3/5°3/5°Max. Wind Speed12.5m/s12.5m/sPowerBattery8×6V/420Ah8×6V/420AhCharger48V/35A48V/60ADrive MotorAC 32V/3.3kwAC 32V/3.3kwLift MotorAC 32V/10kwAC 32V/10kwAuxiliary PowerManual Pump12V DCHydraulic Tank Capacity75L75LTireType33x12 D610 Foam-filled Tires355/55 D625 Foam-filled TiresWeightGross9200kg9200kg  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
