Central Machinery Concrete Vibrator Plate Compactor

Vibrating Plate Compactor for Road Construction Application:Designed for compaction in confined areas of granular soil in narrow trenches. These plates are ideal for curbs, gutters, around tanks,forms, columns, footings, guard railings, drainage ditches, gas and sewer works, and building construction.Advantages: Hydraulic bidirectional plate compactorPowered by Honda450×600mm base plate The plate material is  cast iron Plate compactor technicial data ModelSAPC100EngineHonda GX160 5.5HPEngine type4stroke,1cylinder,OHV,air-cooledRated output5.5hpMax forward speed40cm/sVibration frequency5400rpmCompaction depth500mmPlate size45*60cmPlate materialcast ironPacking Weight140kgsDimension48*45*129(L*W*H CM)20GP40PCS40GP84PCS plate compactor seriesModelSAPC200EngineHonda GX270 9HPEngine type4stroke,1cylinder,OHV,air-cooledRated output9hpMax forward speed35cm/sVibration frequency5400rpmCompaction depth600mmPlate size50*70cmPlate materialcast ironPacking Weight152kgsDimension85*60*120(L*W*H CM)20GP40PCS40GP84PCS  SpecificationsDesigned for compaction in confined areas of granular soil in narrow trenches.Features and Benefits:*Foldable handle for easy transportation and stock. (straight handle is also available)*Complete sealed belt cover to prevent sand and soil in.*Built-in wheels for easy transport.*Centrally mounted fully enclosed exciter for an even spread of compactive force over the whole base plate*Throttle control for easy holding working speed.  (Throttle control is available as optional)*Heavy-duty shock mounts reduce vibration to the upper engine and handle.*Rubber & canvas mat for brick paving compaction as option.*Lifting Hook is available as optional  Specification ModelSAPC-aSAPC-bSAPC-cSAPC-dSAPC-e Engineair-cooled,single cylinder,4-stroke Engine TypePetro,Honda Gx160Petro,Robin EY20Petro,LF200Petro, Copy Robin RB20Diesel engine 170F Power (Hp)5.556.554 Operating Weight (kg)8786878697 Size of Base Plate (LxW) (cm)51x45 Max.Centrifugal Force (KN)20 Vibration Frequency (vpm)4500 Compaction Depth (cm)30 Forward Speed (cm/s)up to 30 Compacted Area (m2/hr)up to 700 Gradeability30% Operating Dimension (LxWxH) (cm)106x45x100 Shipping Size(LxWxH)(cm)60x47x76Specifications are subject to continuous product development1.Reversible Plate compactor SAPC-160Superior compaction in any direction, FORWARD and REVERSE. Used for asphalt, soil, sand, gravel, and mixer soils in the areasof construction, civil or road engineering, gardening ,it is easy to handle ,have high performance, highly durable, easy operation.Low maintenance design-less time and less costly to repair.Features1. Forward & revers, as well as on-spot-compaction.2. Easy-to-reach located controls.3. Large shock mounts reduce vibration to the handle.4. Heavy-duty shock mounts reduce vibration to the upper deck.5. Wear-resistant base plates extend life, open design reduces dirt in.6. Centrally located lifting bar allows easy translportation in and out of trenches.7. Warp around protection cage protects the plate from accidental job-site damage.8. Heavy duty industrial throttle control is available as optional.9. Extension plate is available.  Optional accessoriesl     Trolley wheell     Rubber matl     Extension plate  Specification Data:ModelSAPC-160HDSAPC-160CHSAPC-160DEngineAir-cooled.4-storke,single cylinderEngine TypeHonda GX270Chinese Petrol Engine Chinese Diesel 178F/EPower kw(hp)6.6(9.0)4.8(6.5)4.4(6.0)Weight kg(lbs)161(354)151(332)170(374)/175(386)Frequency vpm4000Centrifugal Force kN30.5Compaction Depth cm(in)50(19)Travel Speed cm/s(in/s)25(10)Efficiency m 2 /hr(fr 2 /hr)570(6100)Plate Size cm(in)73*45(28*18)/73*36(28*14)Extension plate:73*6(28*2.3)Package cm(in)78*48*109(without extension plate)78.5*48*109(without extension plate) Optional Engine:1.B&S 5HP/6.5HP  2. Robin EY28 7.5HP/SABARU EX27 9.0HP3.Kohler  CH395 9.5HP  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
