Zhongyuan 80wires Multi Wire Saw Machine for Cutting Blocks Into Slabs

ZY-MW SERIES MULTI-WIRE SAW MACHINE TECHNICAL DATAZY-MW 76ZY-MW 80ZY-MW 82ZY-MW 84ZY-MW 86MAX.CUTTING LENGTH3200mm3200mm3200mm3200mm3200mmMAX.CUTTING HEIGHT2000mm2000mm2000mm2000mm2000mmSLABS STANDARD THICKNESS19/20mm18/19mm20/30mm18mm18mmMAX.CUTTING SLAB QUANTITY7579818385DIAMOND BEADS DIAMETER5.3/6.3mm5.3/6.3mm5.3/6.3mm5.3mm5.3mmDIAMOND WIRE LENGTH23700mm23700mm23700mm23700mm23700mmMAX.INDIVIDUAL WIRE TENSION180/200/250KG180/200/250KG180/200/250KG180/200/250KG180/200/250KGWIRE SAW SPEED0-35m/s0-35m/s0-35m/s0-35m/s0-35m/sMAIN MOTOR POWER200KW220KW250KW250KW250KWCOOLING WATER2400L/min2400L/min2400L/min2400L/min2400L/minMACHINE LENGTH11800mm11800mm11800mm11800mm11800mmMACHINE HEIGHT5900mm5900mm5900mm5900mm5900mmNET WEIGHT65T65T65T65T65TFunctions and Features:This machine mainly consists of the following main parts: driving system, tension system, lifting system, trolley system, speed regulation system, sprinkler system, and lubrication system. Its main features are as follows:1. This machine abandons the traditional linear roller system and adopts high precision linear sliding track in an all-around way to ensure the stable operation of the vertical column linear slider during the machining process.2. This machine adopts the new international digital control technology to provide a comprehensive guarantee for the smooth operation of the equipment.3. This machine adopts the self-developed tensioning system to ensure the consistency of each wire saw and make the machine run more smoothly.4. This machine adopts a PLC digital control system to realize the modular combination of various parts, display the running status of the equipment in real-time through the display screens, and realize the automatic operation by setting the operating parameters you desired.5. The design of the machine is reasonable, stable operation, convenient operation, small floor space occupied, high processing efficiency, energy-saving an,d environmental protection.6. Various specifications available to cut different widths of blocks, mainly used for processing large slabs of granite, marble and artificial stone. It is the ideal replacement for sand saws and provides more choices for large-scale processing among various stone enterprises.  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
