Children Board Book Making Machine Book Shape Cutting Machine

  Product DescriptionWT-009MQJ die cutting machine is designed for die cutting of various book shapes and holes, widely applied in manufacturing children's books, board books, notebooks, saddle stitch books, paperback books, hardcover book, etc. It is capable of accomplishing precise feeding, automatic collection and scrap removal. Detailed Photos1.Sheet feeding unit: It only needs to place books on the conveying belt, the books can be automatically transferred to the designated position;2.Automatic alignment unit: After the book is fed to designated position by motor driven conveying belt, KEYENCE sensor checks the position of the book and the SMC cylinder aligns it to ensure accurate positioning;3.Servo driven clamping unit: High torque servo motor driven clamping mechanism moves in reciprocating motion to transfer the books into die cutting station;4.Die cutting unit: A range of die cutting tools is available to accommodate various book sizes, the height of cutting tool is adjustable according to the thickness of the book;5.Book collection unit: Finished books are transferred by conveying belt for manual collection; Product ParametersPower supplyAC 380V/50 HZCutting toolsMetal cutting tools/wood cutting toolsTotal power4.5KWControlPLC control + servo systemCutting pressure16TOperators needed1Cutting accuracy±0.20mmDimensionL3550*W1650*H2250MMWeight2500KGBooks sizeMax. 300X300(mm)Min. 100X100(mm)Book typesBoard book, notebook, paperback book, hardcover book, saddle stitch book, etc.Productivity2300PCS/HFinished Book SampleFAQ1.Q: What kind of product is this die-cutting machine mainly used for?A: This die-cutting machine is mainly used for cutting shape of children book,board book, and can also punch the hole.2.Q: What size is the machine suitable for?A: Maximum punching size: 300*400(mm)    Minimum punching size: 100*100 (mm)3.Q: What other products can this die-cutting machine be used for?A: This die-cutting machine is also suitable for particle board, grey board paper, etc./* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
