External Half Coil/Limpet Reactor 20000L for Resin Synthesis, Polymerization

1. Chemical Processing Machine: External half-pipe coil ReactorExternal Half Pipe Coil Heating Reactor is heated by the external coil to supply heat transfer conduction oil, it is an ideal equipment of low power and high heating temperature and large volume. Compared with common jacket reactor, it has many advantages.A) Reduce the thickness of tank and increase its loading capacity.B) Increase heat transfer efficiency.C) Reduce power consumption and cost.D) Reduce the total diameter of tank and be good for the layout of workshop.E) Save steels.Operating principle: Break down or recombined the materials through mixing, filling and cooling, to promote the reaction of polymerization.Components: Body, gears, mixing devices, heating devices, cooling devices, seal, etc.Auxiliary Equipment: Distillation column, head tank, condenser, water separator, collecting cans, filters, etc..Widely used in: Resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.Applicable Field: All the liquid-liquid, liquid-powder reaction industry. Instruction:1).Reactor kettle is the main chemical react production equipment, which is widely used in resins, adhesives, paint, cosmetics, pharmaceutical and other chemical production.2).Break down or Re-combined the molecule through mixing, Heating, cooling, Vacuumize, etc.  Suit for polymerization, hydrogenation, vulcanization, nitration,etc. The reactor is made up of body vessel, jacket vessel, gears, mixing devices, heating devices, cooling devices, seal composition,etc. The auxiliary equipment:Head tank, distillation column, condenser, water separator, collecting cans, dilution tank, filters ect.2. Specification of External half-pipe coil Reactor  TypeItem500L1000L1500L2000L3000L5000L8000L10000L15000L20000L25000L30000L35000LCylinder Size mm900×8001100×12001300×12001400×153001600×15001800×20002100×220002200×25002600×28002800×30003000×34003200×35003200×4000Actual Capacity L6991400216630004066660010038123001945624205310843670640725Outer Tube Size mmΦ76/2Φ76/2Φ76/2Φ76/2Φ89/2Φ89/2Φ89/2Φ89/2Φ89/2Φ89/2Φ89/2Φ89/2Φ89/2Heating Area m21.72.63.84.55.87.51113.218.621263033Inner Coil Size mmΦ38Φ45Φ45Φ45Φ45Φ57Φ57Φ57Φ57Φ57Φ57Φ57Φ57Cooling Area m21.62.73.64.35.7811131821253033Motor Power kw345.55.57.5111518.52230374555  3. Mixing system for reactorMixing system is the core component of reactor, a cutom-made stirrer is your key to success. stirrer selection is related with the material's viscosity, liquid-solid ratio, proportion of liquid, solid's internal pipe coil etc.4. Reactor Series The reaction kettle is widely used for reaction, evaporation, conectration, synthesization, polymerization, mineratization, etc. in chemical industry, medecine, dye, pesticide, organic synthesis, petroleum,food additives, industry of national defense and scientific reserch. Our company is an enterprise specialized in designing and manufacturing reaction kettles, we can design and manufacture various types of reaction kettles for users.Model selection reference of reaction kettleCompositionInstructionsSpecification (L)50-50000Design Pressure (Mpa)Atmospheric Pressure or under pressureMaterialCarbon steel, stainless steel, enamel, graphiteHeating FormsElectrical heating with medium in jacket, external half coil steam heating, external half conduction oil heating, hot water infrared heating etc.Cooling FormsRefrigeration medium in the internal pipe jacketBlending PowerModel selection is made according to material viscosity, liquid-solid ratio, liquid specific gravity, solid specific gravity, solid granularity, rotation speed, paddle type, with or without baffle or internal coil.Stirring blade FormsAnchor type, frame type, flat paddle type, pitched paddle type, ribbon type, turbo type, pusher type and multiple compound typeSealMechanical seal or stuff packing sealInner Surface TreatmentPolished or no polishedDischarge ValveFlanged ball valve, open downward discharge valve and othersTechnological Pipe HoleManhole, sight glass, distillation mouth, imported materials, pressure gauge port, temperature, mouth, mouth filling N2,*After-sales service:1> one year from date of delivery, if any spare parts be broken within warranty and not caused by improperly operation, we would offer the new parts for free. 2> Provide professional after-sales service engineers to  abroad  installation and debugging. * ONE-STOP SERVICESAccording to market and customer demands, our company is continuously researching, developing, upgrading and improving various products, striving to build the firs "one-stop" type cosmetic machinery shopping with machinery & equipment, cosmetic raw material, packing materials, technical consultation and other services *Providing technical support in the aspects of field commissioning and running of the products sold. *Field failure diagnosis and maintenance. *Providing spare parts and fittings, maintenance and servicing plans. *Choosing Jinzong Machinery is choosing professional technical support
