CNC Hydraulic Press Brake Kcn-10032 with Da52s Controller 4+1 Axis

  Electrohydraulic Synchronous CNC Press Brake Model: KCN-10032 4+1 Axis Main functions and features1.Overall welded and processed structure. 2.Electric hydraulic proportional servo synchronization, ensuring repeated accuracy. 3.Within one stroke, bending pressure can be controlled at random point, repeatability precision±0.01, parallelism 0.02. 4.Lower worktable has crowning device to anti deflection & upper tool has wedge compensation device. 5.Switzerland cybelec CNC control system, grating ruler, Rexroth hydraulics, servo motors and other accessories of famous brand are installed for perfect machine performance.  6. Ram stroke(Y1, Y2),backgauge (X, R) are controlled by CNC controller while ball screw and linear guide rail installed for high repeatability precision.  7.Imported ball screw and linear guide are used for rear stopper, to ensure the positioning precision of rear stopper, for processing precision of machine to be higher. technical ParametersNo.itemparameterunit1Nominal pressure1000KN2Table length3200mm3Max.Slider stroke200mm4Max.Shut height460mm5Between columns2700mm6Throat depth400mm7Main motor power7.5KW8Down Speed180mm/s9Pressing Speed12mm/s10Return Speed160mm/s11Control axisX+Y1+Y2+R +W/12X axis Stroke500mm13X axis Speed300mm/s14R axis Stroke150mm15R axis Speed50mm/s16Backgauge Stoppers2/17Overall dimension3700x1750x2630mm18Machine weight7500KGMain configuration NameProducerCNC controllerDA52SMain   motorSiemens         Germany  brandElectrical componentsSchneider        France  brandGear  pumpSunny           USA  brandSeal  ringNOK            Japan  brandHydraulic systemBoschrexroth    Germany  brandBall screw ,Linear guide HIWIN          Taiwan  brandGrating rulerGIVI            Italy  brandTubing connectorEMB            Germany  BrandServo Motor and drive Thinkvo         China brandDA52S CNC controller The compact DA-52s is a complete CNC solution for conventional as well as synchronised press brakes. The panel based control, capable of controlling up to 4 axes, can be integrated in cabinets as well as in an optional pendulant arm housing. Equipped with the Delem user-friendly user interface, the DA-52s provides all main press brake functionality.The unique 'hotkey' navigation gives direct access to the programs in memory and enables quick and easy programming of a product. All common bend parameters are located on one page. For advanced parameters an  additional page can be selected.  The standard accessories are in the below: 1.Anchor bolt 2.Hex nut 3.Seal ring 4.Gasket 5.Grease gun 6.Allen wrench 7.Foot switch 8.Front support arms 9.Electrical box key, control panel key 10. Operation manuals     /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
