PVC Plastic Powder Mixer Machine High-Speed PVC Mixer

SRLSeries powder mixer for plastic extruder units are widely used for mixing, drying, and coloring for all kinds of plastic resin such as PVC , PE, PP. They can also be applied in drying of engineering plastic such as, ABS, PC, etc. This unit is composed of heating and cooling mixers. Hot material from heating mixer is fed into cooling mixer for cooling to eliminate gas and avoid burning. Main Technical ParameterModelSRL-Z100/200SRL-Z200/500SRL-Z300/600SRL-Z500/1250SRL-Z800/1600Total volume (L)100/200200/500300/600500/1250800/1600Effective capacity (L)65/130150/320225/380330/750600/1050Stirring speed (rpm)650/1300/200475/950/130475/950/100430/860/70370/740/50MIxing time (min.)8-128-128-128-128-12Motor power (kw)14/22/7.530/42/1140/55/1155/75/1583/110/22Ovarall dimension (mm)1950*1600*18004580*2240*24704800*2640*24805600&3000*31005170*3200*4480Weight (kg)22003400360065009800Output (kg/h)1653304958251320Pvc pipe production line extrusion extruder machinePVC Pipe Production Line is mainly used in the production of agricultural  drainage, water supply and drainage, and cable laying,etc. purposes. The unit consists of conical double/ parallel double extruder, mold, vacuum forming tank, multi-claw haul-off machine, planetary(chipless) cutting machine, stacker and so on. And the line can be equipped with Comptroller thickening instrument or computer inkjet printer, etc. to achieve the production and manufacture of high-grade tubing. Technical specifications for PVC/UPVC Pipe Production LineModelPipe Spec(mm)Conical twin screw extruderMax output(kg/h)Total power(kw)GWG63-PVCΦ20-Φ63GSZ65/132180-300104GWG160-PVCΦ63-Φ160GSZ65/132180-300105GWG250-PVCΦ75-Φ250GSZ80/156300-450110GWG315-PVCΦ250-Φ315GSZ80/156300-450216GWG450-PVCΦ200-Φ450GSZ92/188650-750290GWG630-PVCΦ315-Φ630GSZ92/188750-850350GWG800-PVCΦ500-Φ800GSZ135/31950-1100410  Parallel twin-screw extruder technical specifications  Motor(KW)Screw diameter(mm)Max.speed(rpm)L/DMax Capacity(kg/h)Weight(kg)GSP75/2837753628:12804100GSP93/3145/55934531:14504700GSP110/3190/1101104531:16806500GSP120/31110/1321204531:18507500GSP135/311601354531:111008400PP PE PPR PERT Pipe Machine Extrusion LinePP/PE Production Line is mainly used in the production of agricultural drainage, water supply and drainage, and cable laying,etc. purposes. The unit consists of conical double/ parallel double extruder, mold, vacuum forming tank, multi-claw haul-off machine, planetary(chipless) cutting machine, stacker and so on. And the line can be equipped with Comptroller thickening instrument or computer inkjet printer, etc. to achieve the production and manufacture of high-grade tubing. Main Features 1) Simple structure in linear type ,easy in installation and maintation.  2) Adopting advanced world famous brand components in pneumatic parts ,electric parts and operation parts.  3) Running in a high automatization and intellectualization 4) Apply a linker to connect with the screw loader ,which can directly online with filling machine    SPECIFICATIONS FOR 25 TON CRAWLER EXCAVATORModel Th specification of pipe (mm)ExtruderMax, output(kg/h)Power of main motor (kw)GWG63Φ20-Φ63 GW65/38 250-30075/90GWG110Φ63-Φ110 GW65/38 300-35090GWG250Φ75-Φ250GW75/38   550-650132/60GWG450Φ160-Φ450GW90/38   750-850250GWG630Φ315-Φ630GW120/33 950-1100 280GWG800Φ400-Φ800GW150/33  1100-1200 315GWG1000Φ630-Φ1000GW150/33  1100-1200315GWG1200Φ800-Φ1200 GW120/33   &GW90/38 1500-1700280/220  Twin Conical Screws Plastic Extruder machine machinesMaintenanceOur panel requires no regular maintenance to uphold their strength,qualities & functions. When using our materials, please remove any dirt,dust,fingerprint, etc. From the face of the panel after fabrication & installation.Over time if the panels do happen to get dirty, a simple wash down with water & a mild detergent(soap)  Detailed PhotosProduct Parameters The twin conical screws extruder is a kind of special equipment for extruding of PVCpower. With different sorts of molds and auxiliary machines, it can produce all sorts of PVC plastic pipe material, profiled material, plate material, sliced material bar material and granulation. It also extrude PP.PE pipe at high speed by changing special barrel.   Computer control or conventional control is optional. According to customers'  requirements, most reasonable screw can be made so as to achieve best plasticity    state and material quality. The screw is made by high precision special digital   screw miller, extruding property can be highly harmonized. It has firstly introduced   advanced technique of producing screws with variable pitch and depth, so that the   material can be more softly sheared and cut. The distribution box is specially   designed, pull force bearing is fully imported, the drive life span can be prolonged.   It can bear larger extruding pressure.     Production Feature   1, Suitable for extrusion all kinds of PVC powder   2, Different molds and auxiliary machine can produce different PVC pipe, profiled,   plat
