China Automatic Pneumatic Vacuum Loader Lifter Vacuum Transfer Feeder Conveyor

China automatic pneumatic vacuum loader lifter vacuum transfer feeder conveyor  The vacuum feeder conveyor consist of vacuum conveyor,weighing hopper,screw conveyor,mixer,vibrating sifter,packing machine,PLC control system,platform etc. The system is totallly full sealed and PLC controlled with the advantage of dust-free and lobor saving.The basic principle of vacuum conveyor system is to move the suspended material such as tablet,capsule in a relatively uniform stream from a feed station or supply source to a delivery point.The vacuum,generated by a vacuum pump or blower,creates a high enough air velocity and low enough solids to air ratio to effectively move the materials. Our vacuum powder transfer system ranges from PL-VC1 to PL-VC10 with capacity up to 10 tons per hour and suitable for transport in bulk bag unloading,dosing,milling,pelleting,screening and batch feeding of process tanks,mixers,and other process equipment.   ModelPowerAir pressureCapacity(kg/Hr)PLVC-11.50.4-0.6400PLVC-22.20.4-0.6600PLVC-33.00.4-0.61200PLVC-45.50.4-0.62000PLVC-55.50.4-0.63500PLVC-67.50.4-0.64000PLVC-77.50.4-0.66000The capacity is caculated on the basis of wheat flour and 3 meters conveying distance!for exact capacity of yeast powder,please contact us via the bottom contact information! Main feature of vacuum feeder conveyor1.Dust free conveying and low maintenance 2.Clean easily between batches 3.Move material in any direction 4.Reduce labor cost 5.Made by SUS304 or 316L 6.No tools needed to change the filters 7.Long covneying distance 8.High screening accuracy 9.High handling rate More Pictures   Other related products                                    Pulverizer                                                                     Vibratory Separator                                                                  Bag filler/* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
