Mechatronics Crush Resistance Testing Machine Crush Tester Laboratory Test Machine

Product Description  XHV-03 Crush Tester is applying to do the RCT, ECT, PAT, FCT, CMT, CCT. It is the ideal testing equipment for papermaking, packaging, quality inspection department and so on.Test Standard: ISO13820, ISO3037, ISO7263, ISO12192 , ISO3035, ISO 13821.................etc.Features: 1. Adopt high precision load sensor, the accuracy of force can be controlled better than 1%, usually we control it within 0.5% out of factory.2. Precision ball screw transmission, Aluminum-alloy control panel, reasonable design for upper and lower stainless steel plate.3.Color Touch screen operation system, automatic complete operation, has statistics function.4. Micro-printer, fast and clear printing5. Professional calibration procedure, user can calibrate the machine easily.7. High performance  motor driven, USA chips control, ensure accurate transmission, fast and high efficient test.8. The crush tester can add thickness test according to customer special requirement.9. Multi units can be selected.Technical Parameter: Force Measurement range0-3000NResolution1NTest Speed(12.5±2.5) mm/min (ECT, RCT, FCT, CMT, CCT, PAT)Parallelism between upper and lower plate
