Hdl-180d1 Hydraulic Drifter Impact Percussion Anchor Drilling Rigs Good Quality

HDL-180D1 Hydraulic Drifter Multifunction Deep Foundation Anchor Drilling Rig   HDL-180D1 top drive drilling rig is mainly for complex formation. The top drifter has high power -vibration, it's able to drill in hard rock without compressor or DTH hammer within 30-m-depth.  Specification  If you need more detail, pls kindly send email to us SpecificationsHDL-180D1Hole diameter(mm)φ100~φ250Hole depth(m) 150~180Hole angle(°)-12~90Rod diameter(mm)φ73,φ89,φ102,φ114,φ146,φ168,φ219Rated output max torque (max)(N.m)14000Rated rotary max speed(max)(r/min)70Construction SiteProduct Show1. Top drive type rotary head With large torque, high speed, high impact frequency and stable performance.2. Stable hydraulic systemIt is equipped with control valve that is imported with original packaging. It has reliable quality, high performance, long performance life and good controllability.3. Its stroke length is longer, it can combine 4-meter-long drilling rod in one time, has higher efficiency.4. Easy operating  We adopt imported control valve, it is more flexible , reliable and convenient for maintenance.5. The structure design is more stableIt is steady when construction ,  suitable for tunnel construction. And it can reduce the wastage of drilling tools.6. The platform is wider, and so the construction environment is better. Feature&Technology1. The rotary head has high power vibration on the top element. It can achieve the effect of impact drilling without DTH hammer or air compressor, with high efficiency and good effect.2. The drilling tools from outside to inside are all involved in the transmission of the impact power. And that helps reducing inner accident such as jamming or tools truck, thus effectively reduces the working cost and risk.3. Large torque, high rotary speed, high-power impact work makes this machine able to work in wide range of layers, especially for the sand gravel layer, scattered gravel, sand layer, rock and soil and other unstable layers that need impact drilling. It has high penetration rate and drilling efficiency. And when the local layer moisture content is too high, using DTH hammer is almost the only choice.4. The machine is mainly applied in: wall protection of foundation pit, protection of slope support, all kinds of guide hole construction, such as various types of engineering tunnel pipe shed. Production FlowAbout us    WUXI ANMAN CONSTRUCTION MACHINERY CO.,LTD. is a construciton machinery manufacturer which integrates of scientific researching, producing and sales, especially in the R&D and product customization for marketing demands. The drilling rigs are major in foundation construction, including high-speed railway,city subway, tunnel, basement under high-rise buildings, water-proof construction,etc. By different techniques, we have Multifunctional Anchor Drilling Rig (HDL Series), Anchor Drilling Rig(MXL, MX Series), Jet grouting Drilling Rig (SJ, SJL Series). All of them are the essential engineering machines in the construction projects. TrainingCertificatePackaging and TransportationFactory show    ExhibitionOur products have been exported to many oversea countries such as Malaysia, Vietnam, Singapore, Iran, England, Canada, Kampuchea, Indonesia and Africa.Meanwhile, welcome join us to be our agents and create the overseas markets.  FAQ:Q: Are you original manufacturer?A: Yes, ANMAN is manufacture in anchor and jet grouting machinery in China for more than 40 years. Q: Which payment terms are available to us?A: T/T term or L/C term. On T/T term, 30% down payment is required in advance, and 70% balance shall be settled before shipment. On L/C term, a 100% irrevocable L/C without "soft clauses" can be accepted. Q: Which Incoterms 2010 terms can we work?A: ANMAN is a professional and international company, accept all Incoterms 2010 terms, normally we work on FOB, CIF, CFR, CIP. Q: How long will the delivery time take?A: Normally it will take about 30-40 days to produce the ordered machines. Q: How about your sales performance in China?A: We have more than 2000 active customers in China. The leading market share of same function products in domestic fields./* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
