2000m skid mounted land drilling rig Product Usage HW2000/600 drilling rig is mainly used for drilling and exploration of water resource, medium and shallow petroleum, natural gas, coalbed methane and geothermy, also used for geology, mine construction and other engineering borehole. Structure Features 1.Mechanical transmission, rotary table rotation, low center of gravity, smooth transmission, strong and durable, reliable operation, good sealing. 2.Reasonable structure for easy maintenance and repair. 3.Available to match with cathead device to tighten and loosen drilling tools. Main Parameters Drilling depth(Φ89mm drill pipe ) (m) 20002000ID of rotary table (mm) Φ435Φ660Rotating speed of rotary table(forward ,reverse) (r/min) 48 69 110 19037 52 84 145Max. output torque of rotary table (kN.m) 1821Max. hoisting capacity of single rope (kN) 9090Hoisting speed of winch(second layer) (m/s) 0.84 1.90 3.3 0.84 1.90 3.3Input rotating speed of clutch (r/min) 730730Traveling system4*54*5Matching PowerDiesel motor6135AN 150Ps6135AN 150Ps Electric motorY315S4 110kWY315S4 110kWOverall dimensions (L*W*H) (mm) 4000*2300*12904320*2300*1290Net weight (exclude power) (kg) /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
