Kr150A Tysim Rotary Drilling Rig Single Load Transportation

Technical SpecificationTechnical Specification of KR90C Rotary Drilling RigTypeKR150ATorque150 kN.mMax. drilling diameter1300/1500mmMax. drilling depth42/52mSpeed of rotation6~30 rpmMax. crowd pressure100 kNMax. crowd pull150 kNMain winch line pull110kNMain winch line speed78m/minAuxiliary winch line pull60 kNAuxiliary winch line speed60 m/minStroke(crowd system)3800 mmMast inclination(lateral)±3°Mast inclination(forward)5° Max. hydraulic pressure34.3 MPaControl hydraulic pressure3.9 MPaTravel speed2.8km/hTraction force229kNOperating height16175mmOperating width3390 mmTransport height3655 mmTransport width3390 mmTransport length14765 mmOverall weight40TChassisTypeSinomachEngineQSB7Product DetailsPerformanceConstruction photosProduct packagingOur advantagesCustomer VisitCertificatesExhibitionOur ServicesWhy Choose Us?1. We are the professional & trustworthy manufacturer of piling machinery in China, best quality & best service.2. Supply professional customized service to meet all your requirements.3. Our rotary drilling rigs have been sold to more than 20 countries, such as Russia, Australia, Thailand, Zambia and others.4. Competitive price.FAQQ1: What is the Warranty of the Rotary Drilling Rig?The warranty period for new machine is one year or 2000 working hours, whichever comes first will be applied.Please contact with us for detailed Warranty Regulation.Q2: What's your service ?We can offer professional technical support and good after-sale service to you.Modification methods will be different according to different models and configurations of your owned excavators.Before modifying, you need to provide configuration, mechanical and hydraulic joints and others.Before modifying, you need to confirm technical specification.How to Contact Us?Send your Inquiry Details in the Below, Click "Send" Now!  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
