Rotary Drilling Rig Zr360L with Best Price

Product Description Brand New  Rotary Drilling Rig ZR360LThe rear main winch with single-layer-rope drum and twin reducers mechanism, which extends service life of the steel wire rope significantly. High construction efficiency due to big flow main pump, multi-gear rotary drive, and two-speed crowd cylinder. More stable structure and stronger bearing capacity due to enhanced mast section, double movable booms with parallel luffing mechanism, large slewing support, and reinforced chassis . One key for folding cathead, fixed mast support. Equipment can be transferred easily and quickly. Folding mast, overall transport height 3580mm. New generation cab with better vision, more comfortable operation, new electrical control panel. 360 degree full view monitoring. Options:Auto-lubrication, spin-off. Product Parameters  NAME SPEC.   Torque(KN.M) 360 Drilling Diameter(mm) 2500 Drilling Depth(m) inter-locking 58/65 Friction 88/100 Drilling Speed(r/min) 6~28 Engine Model Cums QSM11 Rated Power(kw) 298 Rated Engine Speed(r/min) 1900 Max.Crowd Force(kN) 300 Max.Crowd Cylinder Pull(kN) 360 Line Pull(main winch)(kN) 340 Line Speed(main winch)(m/min) 72 Line Pull(aux.winch)(kN) 90 Line Speed(aux.winch)(m/min) 70 Operating Mass(t) 108 Traction Force(kN) 560 Rope diameter(Main winch)(mm) 36 Rope diameter(auxiliary winch)(mm) 22  Detailed Photos       /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
