Sts Series Single Crank Precision Press Machine (STS-200)

Products DescriptionThe advance technical optimized structure of machine designed with CAE dynamic simulation optimization. The machine body is welded high quality steel sheet and treated by tension elimination. The key parts are treated by hard chrome plated/nitrogen Adopted well known controller/driving unit/electromagnetism clutch/equipments, bearing etc. International technology class for press machine, measures machine specification. High quality and high response multi-function processor High memory/program with specialized design Shift driving with high integration multishaft/spreading automatic equipments LCD man-machine interface/high frequency response control/Connection terminalof international website and USB.  NameUnit STS-200 STS-250 STS-300 STS-360 STS-500 STS-600  capacity ton 200250 300 360 500  600 rated tonnage point mm 4/74/7 9/7 8/9 13/7 7/13  stroke mm40/250 40/250 300/250  250/300 350/300 300/350 speed changing s.p.m60-130/20-40 50-110/20-40 20-35/20-35 20-35/15-30 10-25/15-30  15-25/15-20 die height mm 350/550380/550 650/550 550/600 700/650 650/700  maximum counterbalancer capacity kg1000/1200  800 1500 1000/1500 1500 1500 slide adjustment mm100/150 100/150  150/150150/150 150/150 150/150  slide area mm800*800/900*800 800*800 1000*900 900*900/1000*900 1200*1200/1100*1000  1200*1200 bolster area mm900*900/1000*900 900*900 1100*1000 1000*1000/1100*1000 1300*1100/1200*1100 1300*1200  bolster thickness mm 170180 200 200 220 240  side opening mm 400*400/300*400400*300/350*300 400*500/400*500 400*500/400*500 500*650/450*600 500*650/500*650  height of the top surface of bed from floor level mm850 /7501060/1060 750/850 900/950  800/800 700/700 work energy kw*p800/1500 1000/2000 3000/2500 3000/3500 7000/3800 5000/8000  main motor Hp*p VS.40*4VS.40*4 VS.40*4 VS.50*4 VS.60*4 VS.60*4  slide adjusting motor  2*42*4 2*4 2*4 3*4 3*4  frame structure one piece frame one piece frame one piece frame tie rod type tie rod type tie rod type         Company Profile SJR Machinery Co., Ltd. , was founded in 1984, which is the main partner member of China Jiangsu International Economic-Technical Cooperation Corporation. Our company specializes in the manufacture and import/export of brand new industrial machinery and tools. We are capable of producing more than 80 types of machines.Sincerely welcoming you to contact us for more information, we look forward to becoming your supplier in the near future. Exhibition Customer Photos Certifications /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
