8 Ton Lifting Crawler Crane Spidercrane Foldable Telescopic Construction Spider Crane Price

Product Description                                                            8TON SPIDER CRANE1. Full hydraulic transmission, electromechanical dual use, high efficiency, low labor intensity, safe and reliable work2. Each hydraulic system is equipped with a balance valve and hydraulic lock for higher safety performance3. The boom and important structural parts are made of special steel plates, which can reduce the dead weight of Marine crane and improve its           performance4. The slewing bearing part is made of 50 manganese forging material with inner tooth turntable5. Cold work molding, 8 - prism structure, give full play to the mechanical properties of the material6. Boom adopts hydraulic cylinder telescopic, more safe and reliable work7. Night lights were installed to extend the working hours8. Optional cab, negative arm and three-phase operation9. Hydraulic oil pipe rubber pipe adopts double wire ultra-high pressure oil pipe, steel pipe adopts electroplating treatment   Max. operating radius16m×0.2t Maximum ground lift 17mX0.9tWinding plantLifting speed of the hook 0-10m/minSpecification of wire rope Φ11mm×80mRetractor deviceBoom form 5sections of boomBoom length 4.5m-16mRise and fallBoom Angle/time 0-75°/13secGyratory deviceTurn Angle/speed 0-360°(continuous)/60secSupporting legLeg movement form Manual+ Oil pressure automatic support Maximum extension amplitude(mm)6400(L)X6100(A),5300(F)Running gearMoving wayHydraulic motor drive,two speedWalking speed0-5.5km/hGradeability20°(36%)MotorVoltageAC380VEngineProducersYun neiType/displacement YN27GBZ/2.7L Starting modeElectrical startingStarting performance-5°C~40°CFuel/volume Diesel/45LBattery capacity24v 45AHFuel consumption rate230g/kW-hNoise levelRated revolution≤81.5dBA  (1m)Operating systemType of Operation (Boom/leg)Manual operation, manual walking + (remote control need optional) Standard configurationDiesel engine and motor (dual power)Dimension4950*1560*2235mmWorkmanshipBaking paint assembly processDetailed PhotosPackaging & ShippingCompany ProfileFAQ1. who are we?We are based in Shandong, China, start from 2018,sell to Africa(45.00%),Southeast Asia(30.00%),Domestic Market(10.00%),South Asia(5.00%),North America(5.00%),South America(1.00%),Central America(1.00%),Western Europe(1.00%),Oceania(1.00%),Eastern Europe(1.00%). There are total about 301-500 people in our office.2. how can we guarantee quality?Always a pre-production sample before mass production;Always final Inspection before shipment;3.what can you buy from us?Mixer truck,Suction-type sewer scavenger,Vacuum sweeper,Concrete pump truck,Hydraulic aerial cage4. why should you buy from us not from other suppliers?Technology research and development, production and sales integration5. what services can we provide?Accepted Delivery Terms: FOB,CFR,CIF,EXW;Accepted Payment Currency:USD,EUR,JPY,AUD,CNY;Accepted Payment Type: T/T,L/C,Western Union;Language Spoken:English,Chinese  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
