Thhi Fq3033/5025 Four-Bar Linkage Floating Crane

Main Technical ParametersHoisting capacity30t(grab)50t(hook)Working gradeA8Working rangeMax./Min.33m/9.5m25m/9.5mHoisting heightOn the deck/under the deck15m/7m28m/7mWorking speed of MechanismLifting mechanism65m/min40m/minLuffing mechanism50m/minRotary mechanism1.25r/minInstalled Capacity645KWMax. working wind speed20m/sNon-working max. wind speed55m/sMaximum turning radius of tail8.54mPower supplyAC380V 50HzCrane weight≈385tNote: The above parameters for the performance of the existing cases of mature technical parameters are for reference only. We can design and manufacture products according to user's requirements. There are various derivative models of said crane available for customers to choose.It also has various electrical and mechanical protective devices necessary for safe operation. The rotation can be 360 degrees rotary, and the loading and unloading efficiency is high.Mainly installed on special hulls or barges for loading and unloading operation between ship and shores or between ships. The turntable has a lower center of gravity, good stability and flexible operation. It is an ideal loading and unloading equipment for coastal, riverside, lake and inland rivers.  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
