Palfinger 120 Ton 100 Ton Rough Terrain Mobile Crane

Palfinger 120 Ton 100 Ton Rough Terrain Mobile Crane  Product DescriptionModelSRC1200Max Lifting weight120 tMax. Lifting height 67.4 mMax. Lifting moment2820 kN.mEngine brandCumminsEngine power242 kW5-section boom49.7 mSpan8.54m*8.52mDead weight in driving77 tDimension16546*3800*3960 mm1. Strong and Reliable Boom 1) Five sections, U-type boom. Max. boom length is 49m and Max. boom length plus jib is 67m; 2) The maximum lifting torque is 3658KN.m, featuring excellent lifting capacity; 3) The utilization of double-cylinder wire rope telescoping mechanism provides higher efficiency and reliability. 2. Super-long and Practical Jib 1) With jib extending cylinder, the installation of the jib is easy and convenient; 2) The jib can realize elevation angles of 0°, 20°and 40°for lifting. 3. Stable and Reliable Structural Parts 1) Double wall board box type turntable increases rigidity significantly; 2) Large outrigger span effectively enhances stability of the crane. 4. Accurate and Efficient Electro-hydraulic System 1) The configuration of load sensitive variable piston pump and electronic proportional control valve adjusts pump displacement automatically, ensuring stable and accurate control of single movement and combined movement and reducing energy loss significantly; 2) Full color extra-large screen, electric proportional control handle, makes human-machine interaction more comfortable; 3) The retraction and extension of outrigger are operational for both the superstructure and carrier, practical and convenient. 5. Compact and Flexible Carrier 1) Engine: inline six-cylinder diesel engine with maximum power of 242kw/2100r/min; 2) Crane axles: imported axle, efficient and reliable; 3) Brake system: Independent front and rear axle circuit brake. All four wheels are configured with disc brake, which greatly enhances safety and stability ; 4) Steering: 4 steering modes; 5) Maximum gradient: 81% (theoretical value). 6. Complete and User-friendly Function 1) Self-mounting and dismounting counterweights are easy to transport; 2) Remote controller enables remote operation and easy observation; 3) Tiltable cab makes working at height safer and more comfortable. Company information/* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
