5 Ton Telescopic Boom Truck Mounted Mobile Crane for Sale

  Truck mounted crane, Crane Truck,mobile crane Truck, This kind of special truck is mainly used for transporting cargo.In order to Convenient transporting, it install the crane to lifting the cargo. crane style model foldable,telescope.Currently our company produce the Crane truck from 3 tons~40 tons model.General SpecificationName16.1m lifting height  truck mounted crane 10/8 tons Isu-zu Tractor Mounted Crane Applicable crane8-10 TGross weight18000kgCurb weight10550kgDimension9000X2510X3850mmCargo body dimension5700×2290×600mmWheelbase4700mmDrive type4X2Max speed95km/hTire specification11.00R20 16PRTire quantity6Brake systemOil brakeEngine SpecificationEngine manufactureHowo/Isuzu/Schaman/Dongfeng/Sinotruck/Foton/JACEmission standardEuro 5Horse power205hpDisplacement5190mlCrane SpecificationItemsSany 8-ton 4 section Sany 10-ton 4 section Max lifting capacity(kg)8000 8000 10000 10000Max lifting capacity at full extension(kg)800110013001500Working radius(m)1411.51412Max lifting height(m)16.113.516.114Crane weight(kg)3820331538003765Outrigger span(m)2280--56002280-55802280--56002280--5580Rotation angle360 full rotation360 full rotation360 full rotation360 full rotationLHD or RHD telescopic boom crane truck high cost performance truck mounted crane 1. Truck crane is specially designed and produced on the basis of common cargo trucks or dump trucks, but need strong chassis frame with high strength to support the crane when lifting heavy cargos. 2. Our product type is available in 1 tons~200 tons capacity crane, correspondingly the truck chassis wheel drive from4x2/4x4/6x2/6x4/6x6/8x4/x10x4. 3. Special crane design:common the end of crane is a hook linked with stee rope, but we can mount a gripping device, holder or other special designed mechanism to achieve the functions of gripping action to hold cargos, not always hooking cargo. 4. Hydraulic system: all the actions of crane and outriggers are driving by hydraulic system, high quality sealed oil cylinder and hydraulic pipe,etc.5. Control system: for lifting capacity under 6 tons, crane is controlled by the operation handles on both sides; over 8 tons, on the top of crane, there is a seat and operation handles on the top of crane.6. Cargo box: box length from 3meters to 10 meters and can produce according to your special requirements, you can check from the following photos below.Testing in factory before loading&delivery Project cases   /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
