Lb Explosion-Proof Single Girder Overhead Crane

LB Explosion-proof Single Girder Overhead CraneProduct Name: LB Explosion-proof Single Girder Overhead CraneExplosion-proof Grade: ExdIIBT4/ExdIICT4Work Duty: A4Lifting Height: 6, 9, 12, 18, 24m The design, manufacture, installation and operation of LB explosion-proof single girder overhead crane meet the requirement of JB/T 10219 standard. This crane is equipped with HB explosion-proof wire-rope electric hoist which is a light type equipment. Description The design, manufacture, installation and operation of LB explosion-proof single girder overhead crane meet the requirement of JB/T 10219 standard. This explosion-proof single girder overhead crane is equipped with HB explosion-proof wire-rope electric hoist which is a light type equipment.With explosion-proof grade of ExdIIBT4 or ExdIICT4, this explosion-proof single girder overhead crane can be used at workshops with initiation ability lower than IIB or IIC, and danger area 1 or 2 (according to GB3836.1-2000). The explosion-proof performance of motor and all electric equipment meets the requirement of GB3836.2-2000.  Lifting weight: 1-16 tonsLifting height: 1-30 metersSpan: 7.5-24.5 metersWorking level: IntermediateWorking environment: -25ºC~+40ºCExplosion-proof grade: IIB or IIC, Grade 3 or 4 explosion-proof Span m 7.5 10.5 13.5 16.5 19.5 22.5 25.5 Capacity t 1~31.5t Total weight kg 1781~12086 Trolley weight kg 405~740 Max. Wheel load kn 13.5~90.94 Travel rail   P24~P43 Lifting speed m/min 0.8/5 0.8/5 0.8/5 0.8/5 0.8/5 0.8/5 0.8/5 Lifting height m ≥ 6 ≥ 6 ≥ 6 ≥ 6 ≥ 6 ≥ 6 ≥ 6 Total motor power kw 4.31 4.31 4.31 4.31 4.67 4.67 4.67 Crane speed m/min 3-30 3-30 3-30 3-30 3-30 3-30 3-30 Trolley speed m/min 2-20 2-20 2-20 2-20 2-20 2-20 2-20 Working duty   M3/A3-M5/A5 Explosion proof grade / Exd ll BT4/ Exd II CT4 /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
