Gooda High Quality CNC Vertical Machining Center Milling Machine (GDVL-866NC)

GDVL-886NC GooDa CNC Vertical machining centerThe Features of this modelThis Vertical machining center machine tool has mechatronics design and stylish look. It cuts precisely, after the workpiece is clamped once, the machine tool can automatically and continuously complete the processing of multiple processes such as milling, drilling, boring, expanding, reaming, countersinking, tapping and so on.Advantages of GOODA Machining CenterThe machine adopts column-fixed and cross-sliding table moving structure. X, Y, Z axis adopt linear rolling guide, the whole machine has high rigidity, high stability and high reliability. The large-flow fully enclosed protection has beautiful appearance, convenient operation and maintenance.  GDVL-886NC  is suitable for the multi-variety processing of complex parts such as medium and small boxes, plates, plates, shells, etc.It is widely used in auto parts, valves, engineering machinery, IT equipment, optical equipment, medical equipment and aviation Aerospace and other industries.·Aseismatic capability, high strength and good quality    ItemUnitSpecificationProcess Range(X/Y/Z)Three axis travel distancemm860/600/600Distance from spindle center line to column guide surfacemm650Distance from spindle nose to work bench surfacemm125~725Work BenchWork bench size mm1000×550 MAX Loadkg650 T-Slot 5×18×100Spindle Spindle Speedrpm10000 Spindle Taper-BT40Spindle Motor PowerkW7.5/11Speed Rapid Moving (X/Y/Z)m/min36/36/36 Rapid Feeding Speedm/min10/10/10Tool MagazineTool Magazine Numberpcs24Tool MAX Diameter/length/weight  Æ75mm/300mm/7kgTool MAX Diameter (Full/Empty)mm75/150Tool selection method any/sequenceTool Changing time (from one tool to another)S1.8Machine Accuracy(X/Y/Z)Positioning Accuracymm0.008(X/Y/Z)Re-Positioning Accuracymm0.005Others Air source/Air pressure 280L/min  6~8barTotal electrical capacity of the machineKVA20Water tank capacityL400Machine size(X×Y×Z)mm2700×2900×2750Machine weightkg5300Machine Main configurationNo ItemQuantityNote1Mitsubishi M80B CNC system1 2Handheld operating unit1 3Disc Tool Magazine124 units4Automatic lubrication system1 5LED Warning Light1 6Spindle blowing device1 7Air curtain protection1 8Flashlight1 9Attached accessories1 10 Attached Technical agreement1 Transmission: The three-axis motor and high-precision ball screw adopt a direct drive method. The ball screw is pre-tensioned and installed to improve transmission rigidity and positioning accuracy. The three linear coordinate axes all use linear rolling guides, the machine tool has low vibration during high-speed feed and no crawling during low-speed feed.  Tool Magazine: We use disc magazine with high quality and stable functionality.  General requirements for the Machine Required environmentKeep the temperature at a balanced level, especially during precise cutting.Working temperature10ºC~40ºC, when 20ºC, humidity should be around: 40~75%To keep the static accuracy of the machine within the specified range, the best temperature is within 15ºC~25ºC, and the temperature difference should not exceed ±2ºC/24h.Power supply voltage: 3-phase, 380V, voltage fluctuation within ±10%, power supply frequency: 50HZ.If the voltage in the area is unstable, the machine should be equipped with a regulated power supply to ensure the normal operation of the machine tool.The machine should have a reliable grounding: the grounding wire should be copper wire, the wire diameter should not be less than 10mm², and the grounding resistance should be less than 4 ohms.In order to ensure the normal working performance of the machine, if the compressed air of the air source does not meet the requirements, a set of air source purification devices (dehumidification, degreasing, filtration) should be in placed before the machine's air intake.Keep the machine away from direct sunlight, intense vibration, high heat, high-frequency generators and electric welding machines, etc., to avoid machine production failure or loss of machine tool accuracy.GOODA Packing and ShippingGOODA Company Profile  /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
