Horizontal Machining Center 6 Axis Drilling Tapping Milling Compound Machine

Horizontal Machining Center 6 Axis Drilling Tapping Milling Compound Machine I.Product structure1.High rigid structure, strong stability; 2.Suitable for medium and large bulk of copper, zinc alloy, aluminum alloy, stainless steel and steel parts processing; 3.High-quality castings, the structure has been analyzed by finite element to achieve high stability;II.Parameter:NameUnitModelZSK4860ZSK4880ZSK4810Number of spindle  6812Spindle taper BT40BT40BT40Spindle center distanceMm120120120Extension length of main shaftMm100100100Spindle sleeve diameterMmφ105φ105φ105Spindle speedr/min1-30001-30001-3000X/Y/Z feed rateMM3000MM3000MM3000MMSpindle box stroke(X axis)MM400600600(customized)Max drill diameter(Copper)MM50MM50MM50MMWorkbench sizeMM400*500400*500400*500Workbench stroke(Y axis)MM300mm300mm300mmMid-tow itinerary(Z axis)MM450mm450mm450mmDistance between spindle end face and worktable end faceMm294-744MM294-744MM294-744MMSpindle motor powerKW5.5KW5.5KW*25.5KW*2DimensionMM220*1830*25002200*2030*20002200*2030*2000WeightKG4150KG4250KG4600KG  III.Production workshopIV.Package and LoadingV.Certificate:Quanzhou Yueli Automation Equipment Co.,Ltd was founded in 2013,which covers an area of 3000 square meters. The company is located at the China Plumb Town--Nanan, Fujian. It is a production enterprise lead by drilling tapping compound machine, drilling tapping centers and drilling tapping milling process center. The company is committed to serving various of industries such as sanitary ware, fire protection valves, hardware, electrical hardware, aerospace, machine manufacturing and so on. If you have any interest, pls feel free to contact at any time. /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
