High Speed 20000rpm Automatic Servo Motor Drilling and Tapping Machining Center

Product DescriptionTC-1600The series of high-speed precision CNC drilling and tapping machining centers are classic models developed to meet the requirements of high speed, high cost performance and high reliability. This series of machine tools can complete milling, drilling, tapping and other processes. It has the characteristics of high precision, high speed and high efficiency. It is suitable for small metal structural parts, 3C, automotive consumer products, 5G communication cavities and related components and other industries.You can choose different CNC control system with different price : Mitsubishi, TAIWAN SYNTEC, FANUC Oi-MF plus(5) or others.Detailed PhotosProduct ParametersModelTC-1600TravelX axis travelmm1600Y axis travelmm500Z axis travelmm500Distance between spindle and tablemm150-450TableSizemm400*1700MAX Loadkg450T slot size 3-14*121SpindleTaper BT30diameter Φ100speedrpm20000Driving type Direct drivingThree axisMotor rateKW5.5Cutting feedm/min10Rapid feedm/min30/30/48Arm type Tool magazineTool capacityT21Maximum length/ weight of toolmm/kg200/3Maximum diameter of tool (no tool) φ60/φ80Tool change time (T-T)s1.6AccuracyPositioning accuracy (X/Y/Z)mm0.012Repeat positioning accuracy (X/Y/Z)mm0.006OtherDimensionmm3900*2300*2500Power capacityKVA15Weightkg6500Packaging & ShippingFAQ1. MOQ   1 set2. DELIVERY TIME       It depends on the machine and model you choose. Mostly 2 months - 4 months. All machines are 100% new and not used.  3.  PAYMENT TERM    T/T 30% down payment when order, 70% balance payment before shipment.4. WARRANTY PERIOD   13 months from the date of B/L, during the warranty period, daily damage parts will be supplied freely,  the after sale service will be done by dealers . After warranty period, the spare parts will be supplied at factory price.5. Customized products     We can design and manufacture according to your specific requirements, such as change the CNC control systems, change the spindle nose taper, upgrade the standard motor and more. You do not have to hesitate to contact me./* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
