High Speed CNC Pipe End Beveling MachineFeatures:1. With automatic self-center chucking function2. Can process single V, double V, U type bevel3. High speedy beveling. For example, for a stainless steel pipe (diameter: 610mm, thickness: 25mm), it takes 2 minutes to bevel 37.5 degrees4. Suitable for C. S / S. S/ Alloy Steel pipe spool fabrication6 .Five models available( 16"type, 24"type, 32" type, 48" type,60" type);7. With automatic self-centering chuck;8. With hydraulic elevating and turning device for both ends efficient beveling;9.end (diameter: 610mm, thickness: 25mm). AUTO Hign Speed CNC Pipe End Beveling Machine is applicable to bevel and face the pipe end with Elevating Conveyors for Centering, suitable for various materials such as carbon steel, alloy steel, stainless steel, etc. It can process single V, double V, J, U type bevels and realizes two pipe ends beveled by elevating & turning-round carriage, which can turn in 180 degree in 30 seconds to bevel and face another pipe end.We can also do the following services for you: 1Planning your workshop, even the plot and providing the most suitable layout2Providing all solutions including material shot blasting and painting, cutting, edge beveling, fitting-up, welding, handling, non-destructive testing(DR/UR), PWHT3Providing management solution covering the entire lifecycle of a project from its preliminary material list, through planning, designing and to final implementation4Providing fast installation and dismantling solution of fabrication workshop5Providing Pre-WPS and supporting clients to do WPS/PQR that meeting API650, ASME, AWS standards6We can help you to get average 0.25manhour/DI layout design Pipe Spool Fabrication Machines1Pipe Cutting& Beveling All-in-one Machine>Suitable for pipes not larger than 8",max.thickness:20mm>Cutting efficiency:100times/8hrs>PLC control with automatic measuring to guarantee the same processing cycle>Widely used for small bore C.S/S.S production lines2High Speed Band-saw Cutting Machine>Three models available(16"type,24"type",48"type)>PLC system control;self-measuring function with precision:±0.5mm>Using hydraulic self-centering chuck>It only takes 6 minutes to cut a 24" pipe of 25mm thickness>Widely used for C.S/S.S production lines.3High Speed CNC Pipe End Beveling Machine>Automatic self-centering chuck>Single V,double V,U type bevel>Can be matched with pipe end turning devic>High speed beveling:for example,it only takes 2.5minutes to get a 37.5 degree bevel for a S.S pipe end(diameter :610mm,thickness:25mm)>Several models available:16",24",32",48"4Two / Multi- Axis CNC Flame/Plasma Cutting Machine>High efficient pipe cutting with automatic self-measuring function, pipe end beveling, intersection line profiling for both main and branch pipe.>Five/multi-axis cutting machine can profile more complicated outlines with various bevel type>Standard machine suitable for pipes nor larger than 24''5Multi-function Pipe Fitting-up Station>Suitable for flange,elbow,tee,reducer to pipe and special T-joint fitting-up.>Light-duty type(manual) and heavy-duty type(motorized) are available.>Different types available, 8" type, 24" type, 32" type, 48" type, 60" type6Automatic Pipe Welding Station>With two welding heads>TIG/MIG/SAW are optional>PLC system control & WPS programmed>Max. efficiency fo reach welding head can be 400D.I/8hrs even use TIG/MIG technology.>Different types available, 8" type, 24" type, 32" type, 48" type, 60" type7Conveyor Handling System>used for pipe convenient transporation during in pipe spool fabrication.>Its speed is adjustable between 2M to 20M/min.For more information, please contact us, thank you!Our company view Nanjing Auto Electric Co., Ltd (NAEC) was established in 2001, taking promoting "Lean Fabrication to Global Energy Engineering Industry" as its mission, NAEC's core business is to provide Lean-fabrication One-stop Solution to energy engineering contractors and fabricators. With advanced innovation ability and continuous integration of new technology & processes, NAEC's solution ensure its users high quality and efficient fabrication, and make itself become worldwide clients' most preferred partner. Our Strategic Clients are EPC companies, Contractors or Fabricators in Onshore Oil & Gas Exploration, Transportation, Storage, Refinery & Chemical EPC companies, Contractors, Fabricators or Equipment Manufacturers in Offshore Oil & Gas Exploration, Treatment, Transportation & Storage EPC companies, Contractors or Fabricators in Nuclear Power, Wind Power, or Thermal Power Various Energy Engineering Equipment Manufacturers We provide Lean-fabrication One-stop Solution for Energy Engineering EPC Companies/ Contractors/ Fabricators, Based on Following Systems: NAEC Lean-fabrication Mode NAEC Lean-fabrication Management System NAEC Lean-fabrication Production System NAEC Lean-fabrication One-stop Solution can help engineering fabrication operators to solve project problems. It can organize fabr
