Transmission Tower   FINCM  Communication Tower CNC  Hydraulic Punching Marking Cutting Machine

Product DescriptionAPM2020   FINCM  Communication Tower CNC  Hydraulic Punching Marking Cutting MachineIt is mainly used for customers to manufacture angle steel components, complete typing, punching, fixed length cutting on anglesteel. Simple operation, high production efficiency.   Technical specification of APM2020CAngle size63mm×63mm×4mm ~ 200mm×200mm×20mmMax. punching diameterφ25.5mm(20mm thickness, Q345)Nominal punching force1100KNQuantity of punching head per side3The quantity of punching row per sidearbitrarinessThe quantity of character group4 groupsDimension of characters14×10mm(10)Nominal Marking force1030KN1030KNMax. length of the raw angle14mCutting modeSingle-blade shearingNominal Shearing force4300KNQuantity of CNC axes3Angle feeding Speed40m/min, the efficiency is about 1000 holes/hourHydraulic station cooling methodwater coolingAngle feeding Speed: 40m/min, the effiency is about 1000 holes/hourThe finished angle conveyor is rotated to one side by pneumatic power. The max. Length of finished angle is 8 m.There are four transverse conveyors which can infeed automatically.Type of programming: Keyboard input, USB interface input, floppy disc input.Working environment:Working temperature: 0~ 40 degreePower: Three phase four wire systemAC Voltage: 380VFluctuation of voltage: ± 10%Frequency: 50 HzMain outsourcing components list of APM2020C:Serial No.NameBrandCountry1AC Servo MotorPanasonicJapan2Orientation moduleMitsubishiJapan3PLCMitsubishiJapan4Unloading valveATOS/YUKENItaly/Taiwan5Relief valveATOS/YUKEN6Electro-hydraulic directional valveATOS/YUKEN7Solenoid reversing valveATOS/YUKEN8Single direction valveATOS/YUKEN9Valve plateSMC/CKDJapan10Air valveSMC/CKD11CylinderSMC/CKD12Triple jointSMC/CKD13ComputerLENOVOChina  Relateed Products  Company ProfileShandong FIN C N C MACHINE CO., LTD is located in Jinan high tech Development Zone, is committed to the development, research, design, manufacture, sales of CNC machine tools, such as processing angle bar, beam channel profiles, steel plates, tubesheet and flanges. It is mainly used in iron tower, steel structure, heat exchanger, boiler, bridge, truck and other industries.FIN CNC machines exported to 50+ countries across globe market. Our company has strong R & D center with 30 engineers team, they have 20 years of experience ; 280 staff, plant area about 270,000 sqm. Main products: CNC Angle Line, CNC Beam Drilling Sawing Machine, CNC Plate Drilling Machine, CNC Rail Processing Machine, CNC Tubesheet Flange Drilling Machine, Truck beam plate punching machine. The company drafted many China national standards for C N C angle lineCooperatine Supplier Product Process ControlSales NetworkOur Service  FAQ 1. When can you arrange shipment?  For machines available in stock, the shipment can be arranged within 15 days after getting advance payment or L/C;  For machines non available in stock, the shipment can be arranged with 60 days after getting advance payment or L/C.2. What can you do if my machines have problems?    1) We can send you free components if machines are in warranty period;    2) 24 hours service on line;    3) We can assign our engineers to serve you if you want.3. Do you provide machine operation training?    Yes. We can send professional engineers to the working site for machine's installation, commissioning and operation training.4. Which machine model shall I choose when I purchase from you?    Please share us your material size and your processing request, then we will recommend our machine most suitable and most      cost effective for your work demand.5. What's your machine's market share in China?    Our market share in China is about 70%+, and we've exported to 50+ countries across the globe market, since year 1998.   /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
