Diamond Cutting Wheel Lathe/ Alloy Wheel CNC Lathe Rim Repair Vertical Machine

  Diamond Cutting Wheel Lathe/ Alloy Wheel CNC Lathe Rim Repair Vertical MachineProduct Description Specification ModelWRC30VMax.Swing over bed800mmMax.Diameter  of alloy wheel720mmChuck dia400mmSpindle speed50-1500rpmCutting speed0.1-1000mm/minStations of tool carrier4 position tool postMax.Size of tool post25×25mmMain motor power5.5kWAccuracy0.015 mmRepeatability0.012mmNet Weight≈3200kgMachine size2250×1960×2300mmStandard Components 1.Diamond Cutter 2.3-Jaws Manual Chuck(With Special Soft Jaws) 3.Diamond Digital Probe Tip 4.Taiwan SYNTEC Controller 5.Manual Quick Change Toolpost,Four-station; 6.Work Lighting System; 7.Automatic Lubrication System; 8.Cooling System; 9.Full Cover (Security Guard Door); 10.Accesssories Tools and Tool Box 11.Wheel Curve Optimize Software Services: 1-After-sales services: Warranty is one year; we would offer the parts (quality problem) free of charge during this period, freight collect. 2-Alloy Wheel Refurbishemnt Advice from REAL WORLD experts in the Diamond Cutting and Alloy Wheel Refurbishment industry 3-Mechanical Support 4-Software Support 5-Comprehensive Training 6-Probe alloy wheel profile Just PROBE & Diamond CUT ! Once the machine has automatically probed the wheel profile there is no need for you to waste time programming our Alloy Wheel lathe we have taken care of that for you. Just cut the wheel and store the profile on the system. Build up a library of Alloy wheel profiles.We saved you time so you can cut more wheels! The machine work steps 1-Probe alloy wheel profile,transformation G code 2-Diamond cut the wheel.       /* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
