CNC Straight Flame Cutting Machine Oxygen Cutting Acetylene Cutting

The portable CNC plasma cutting machine is a cantilever structure and can be equipped with plasma cutting.It is a high-efficiency, energy-saving cutting equipment, light weight and economical CNC plasma cutting machine.Specification:  ModelCNC-4000Rail distance4000mmDriver modeBilateral driveRail No.24/38KGEffective cutting width3200mmTorch lift stroke170mmCutting machine moving speed50-8000mm/minPower supply modelUSA Hypertherm PowerMax105Cutting steel plate thicknessMild Steel: 25mm Stainless Steel:22mmperforation capacityMild Steel:16mminput powerAC220V 50Hz 1Pcut surface roughnessRa12.5Diagonal difference≤0.5(1000×1000square dash)positioning error≤0.5mm/mGas sourcecompressed airCNC plasma cutting machines are classified according to their working methods:Dry plasma cutting machineSemi-dry plasma cutting machineUnderwater plasma cutting machineAccording to cutting quality:Ordinary plasma cutting machineFine Plasma Cutting MachineLaser-like plasma cutting machine, etc.According to the structure, it is divided into:Portable Plasma Oxygen Cutting MachineCNC flame straight cutting machineCNC flame plasma cutting machineDesktop CNC plasma flame cutting machineFeatures:1.The rack drive adopts the motor to drive the rack and pinion bilateral drive;2.Steel belt drive is adopted between the active and driven cutting torch frames. The steel belt has high strength and elasticity and is used to drag the driven cutting torch. The guide wheels at both ends of the beam tighten the steel belt, and the driven cutting torch holder can be clamped. Clamp on the front or back of the steel strip for co-directional or symmetrical cutting.3. All the cutting torches and electric lifting mechanisms of the heavy steel plasma CNC cutting machine are all assembled on the main beam4. The CNC flame cutting machine adopts a T-shaped box-type frame, which has a compact structure, beautiful appearance, light weight and small inertia, which is conducive to the rapid cutting and blanking of steel plates.When the acceleration and deceleration conversion is performed rapidly, the machine has the highest walking accuracy. can still be guaranteed.5. A horizontal guide wheel is installed on one side of the CNC Metal plasma flame gas cutting machine drive frame, which can adjust the pressing degree of the eccentric wheel at the bottom of the drive frame to the guide rail, so that the horizontal oxygen propane plasma flame cutting machine can maintain stable guidance during the entire operation./* March 10, 2023 17:59:20 */!function(){function s(e,r){var a,o={};try{e&&e.split(",").forEach(function(e,t){e&&(a=e.match(/(.*?):(.*)$/))&&1
